| Antwerpen 16 August 2012 |
|
 |
|
| Antwerpen 16/08/12 | Westerschelde 21/01/16 | |
|
Name |
MIRAMARIN |
|
Previous names |
2010 Launch as: CMA CGM Kessel 2010 - 03/2011 Miramarin 03/2011 - 02/2012 APL Duba |
|
Type |
Cellular containership |
|
IMO-number |
9409182 |
|
Call sign |
9HA2280 |
|
Flag |
Malta |
|
Port of registry |
Valletta |
|
GT |
73.779 t |
|
DWT |
85.522 t |
|
NT |
42.486 t |
|
Number of 20ft containers |
In hold: 3.020 On deck: 3.552 Total: 6.572 |
|
Container capacity 14t |
4.874 |
|
Reefer capacity |
500 |
|
Length |
299,20 m overall |
|
Breadth |
40,00 m |
|
Draught |
14,52 m |
|
Reg. dimensions L x B xD |
286,88 x 40.00 x 20,31 m |
|
Rule dimensions L x B xD |
286,70 x 40.00 x 24,60 m |
|
Freeboard |
5.823 mm |
|
Depth |
24,60 m |
|
Speed |
24,1 knots |
|
Built |
2010 |
|
Keel laid |
10/04/2009 |
|
Launch date |
06/06/2009 |
|
Date of completion |
20/01/2010 |
|
Builder |
Hanjin Heavy Industries & Construction Co., Ltd. Busan South Korea |
|
Yard number |
N203 |
|
Hull material |
Steel |
|
Watertight compartments |
11 |
|
Main engine |
1x MAN B&W 10K98MC-C - 2 stroke 10 cylinder 980 x 2.400 mm combustion engine 57.100 kW / 77.582 hp at 104,0 rpm Built: 31/12/2008 Builder: Doosan Heavy Industries & Construction Co., Ltd., Changwon - South Korea |
|
Propellers |
1x Screw propeller solid - aft at 104 rpm |
|
Boilers |
1x Auxiliary boiler WTB 76,00 m² - 10,0 bar 1x Economizer EGE 713,00 m² - 10,0 bar Builder: Kangrim Heavy Industrial Co., Ltd., Changwon - South Korea |
|
Generators |
4x Hyundai/Himsen 9H25/33 main diesel generatorsets each 2.625 kVA - 2.100 kW - 3.003 hp |
|
Emergency generator |
1x Diesel generatorset 313 kVA - 250 kW - 401 hp |
|
Bow thruster |
1x 2.000 kW |
|
Number of holds |
8 |
|
Total capacity of holds |
365.563,87 m³ |
|
Tank capacities |
Fuel oil: 9.887,4 m³ Fresh water: 606,7 m³ Water ballast: 18.435,5 m³ |
|
Handling gear |
None |
|
Manager |
Cardiff Marine Inc. 80, Kifissias Av. GR-15125 Amaroussion Greece |
|
Owner |
DryShips Inc. 80 Kifissias Avenue Marousi - Athens Greece |
|
Registered owner |
South West Container Lines Limited |
|
Previous names & owners |
2010 CMA CGM Kessel - Valletta - Malta - South West Container Lines Ltd. 2010 - 03/2011 Miramarin - Valletta - Malta - South West Container Lines Ltd. 03/2011 - 02/2012 APL Dubai - Charted: American President Lines |
|
Renamed |
2021 KMTC Delhi South Korea, Jeju - Call sign: D7WN Owner: Korea Marine Transport Co., Ltd. Commercial manager: Korea Marine Transport Co., Ltd. ISM manager: KMTC Ship Management Co., Ltd. |
|
Latest data adjustment |
07 July 2024 |
