Westerschelde 10 January 2020 |
 |
 |
 |
 |
 |
||||
| WS 10/01/20 | Westerschelde 08/01/20 | Westerschelde 08/01/20 | Westerschelde 18/11/20 | Westerschelde 15/11/19 |
|
Name |
HAWK HUNTER |
|
Previous names |
2009 Launch as: CPO Boston 2009 - 2017 Cap Hamilton |
|
Type |
Cellular containership |
|
IMO-number |
9439498 |
|
Call sign |
ONKG |
|
Flag |
Belgium |
|
Port of registry |
Antwerpen |
|
Previous flags |
2009 - 2019 Liberia, Monrovia - Call sign: A8RH6 |
|
GT |
41.358 t |
|
DWT |
51.744 t |
|
NT |
24.234 t |
|
Number of 20ft containers |
On deck: 2.689 In hold: 1.566 Total: 4.255 |
|
Number of 40ft containers |
2.101 |
|
Container capacity 14t |
3.000 |
|
Reefer capacity |
On deck: 372 plugs In hold: 188 plugs Total: 560 plugs |
|
Length |
262,05 m overall 249,15 m registered |
|
Breadth |
32,20 m |
|
Draught |
Max.: 12,50 m |
|
Freeboard |
4.311 mm |
|
Depth |
19,30 m |
|
Speed |
Service: 24,1 knots Max.: 26,60 knots |
|
Built |
2009 |
|
Keel laid |
13/10/2008 |
|
Launch date |
19/12/2008 |
|
Date of completion |
30/01/2009 |
|
Builder |
Hyundai Heavy Industries Co., Ltd. 1, Cheonha-dong, Dong-gu Ulsan 682-792 Republic of Korea |
|
Yard number |
2057 |
|
Hull material |
Shipbuilding steel (standard) |
|
Hull type |
Double bottom, continuous from peak to peak bulkhead |
|
Watertight bulkheads |
9 |
|
Continuous decks |
2 |
|
Main engine |
1x Sulzer 8RTA82C - 2 stroke 8 cylinder 820 x 2.646 mm combustion engine 36.160 kW at 102,0 rpm Year of manufacture: 2008 Manufacturer: Hyundai Engine & Machinery Co., Ltd. Ulsan Republic of Korea |
|
Propellers |
1x Solid propeller (keyless) - aft at 102,0 rpm |
|
Boilers |
1x Steam boiler, oil fired - 9,0 bar Heating surface: 26,87 m² Year of manufacture: 2008 Manufacturer: Alfa Laval Qingdao Ltd. 86 Guangzhou Road North Jiaozhou 266300 Qingdao , Shandong People's Republic of China 1x Steam boiler, exhaust gas heated - 9,0 bar Heating surface: 172,0 m² Year of manufacture: 2008 Manufacturer: Alfa Laval Aalborg A/S Gasvaerksvej 24 9100 Aalborg Kingdom of Denmark |
|
Electric installations |
2x Plant 450 V - 2.112,5 kVA 2x Plant 450 V - 2.812,8 kVA 1x Plant 450 V - 187,5 kVA 1x Plant 12 V - 300 Ah 1x Plant 24 V - 100 Ah 1x Plant 24 V - 130 Ah 1x Plant 24 V - 200 Ah 1x Plant 24 V - 300 Ah |
|
Generators |
2x Main diesel generatorsets each 2.255 kW / 2.812,8 kVA 2x Main diesel generatorsets each 1.690 kW / 2.112,5 kVA |
|
Emergency generator |
1x Diesel generatorset 187,5 kVA |
|
Batteries |
1x Battery for UPS navigation 300 Ah 1x Battery for start emergency engine 300 Ah 1x Battery for UPS radio 200 Ah 1x Battery for diesel control 130 Ah 1x Battery for automation 100 Ah |
|
Compressed air receivers |
2x Receivers each 10.500 litres - 32,4 bar 1x Receiver 250 litres - 32,4 bar 1x Receiver 200 litres - 8,7 bar 1x Receiver 2.000 litres - 8,6 bar |
|
Bow thruster |
1x Transverse thruster 1.500 kW, forward |
|
Tank capacities |
Heavy fuel oil: 5.200 m³ Marine diesel oil: 200 m³ Fresh water: 300 m³ Ballast water: 13.000 m³ |
|
Anchor equipment |
3x Anchors weight each 12.300 kg Chain length: 687,50 m Diameter: 87 mm |
|
Cargo gear |
Gearless |
|
Crew size |
28 |
|
Manager |
CPO Containerschiffreederei (GmbH & Co.) KG Bleichenbrücke 10 20354 Hamburg Federal Republic of Germany |
|
Registered owner |
CMB - Compagnie Maritime Belge N.V. De Gerlachekaai 20 2000 Antwerpen Belgium |
|
Special annotation |
Hull structural members are partly made of higher tensile steel according to drawings to be kept on board |
|
Renamed |
09/2021 BSG Bahamas Liberia, Monrovia - Call sign: 5LCC6 Owner: MS BSG Bahamas GmbH & Co. KG Manager: CPO Containerschiffreederei (GmbH & Co.) KG |
|
Latest data adjustment |
03 September 2022 |
