Westerschelde 10 April 2020 |
 |
 |
 |
||
| Westerschelde 10/04/20 | Westerschelde 10/04/20 | Westerschelde 15/06/20 | ||
|
Name |
CARTAGENA EXPRESS |
|
Type |
Cellular containership |
|
IMO-number |
9777618 |
|
Call sign |
DJQB2 |
|
Flag |
Germany |
|
Port of registry |
Hamburg |
|
GT |
118.945 t |
|
DWT |
123.490 t |
|
NT |
52.240 |
|
Number of 20ft containers |
10.593 |
|
Container capacity 14t |
7.944 |
|
Reefer plugs |
2.100 |
|
Length |
333,20 m overall 318,00 m between perpendiculars |
|
Breadth |
48,24 m extreme |
|
Draught |
Max: 14,00 m |
|
Depth |
22,46 m |
|
Speed |
Max: 23,0 knots Service: 21,0 knots |
|
Built |
2017 |
|
Keel laid |
01/12/2015 |
|
Launch date |
03/12/2016 |
|
Delivery date |
23/01/2017 |
|
Builder |
Hyundai Samho Heavy Industries Co., Ltd. South Korea |
|
Yard number |
S834 |
|
Hull material |
Steel |
|
Hull type |
Double bottom Double side |
|
Continuous decks |
1 |
|
Main engine |
1x MAN-B&W 7S90ME-C9&10 - 2 stroke single acting 7 cylinder 900 x 3.260 mm combustion engine 34.223 kW / 46.530 hp at 84,0 rpm Builder: MAN Energy Solutions, branch of MAN Energy Solutions SE - Germany |
|
Propellers |
1x Fixed pitch mono-block propeller - aft at 84,0 rpm Builder: Hyundai Heavy Ind. EMD |
|
Boilers |
Auxiliary boiler, composite |
|
Generators |
1x Daihatsu 6DE-33 - 6 stroke 6 cylinder 330 x 440 mm main combustion engine 3.600 kW connected with generator 3.500 kW 4x Daihatsu 8DE-33 - 2 stroke 8 cylinder 330 x 440 mm main combustion engines each 4.800 kW connected with generators each 4.700 kW Builder: Daihatsu Diesel Mfg. Co., Ltd. Moriyama Division |
|
Emergency generator |
1x Doosan V/AD 222 diesel generatorset Builder: Doosan Infracore Co., Ltd. |
|
Bow thruster |
1x Tunnel thruster 3.000 kW / 4.079 bhp, forward |
|
Tank capacities |
Ballast: 31.101,8 m³ |
|
Anchor equipment |
Length: 770,00 m Diameter: 117 mm |
|
Cargo gear |
Gearless |
|
Crew size |
27 |
|
ISM & commercial manager |
Hapag Lloyd Aktiengesellschaft Hapag-Lloyd Haus Ballindamm 25 20095 Hamburg Germany |
|
Registered owner |
Hapag Lloyd Aktiengesellschaft Hapag-Lloyd Haus Ballindamm 25 20095 Hamburg Germany |
|
Latest data adjustment |
19 February 2022 |
