Oostende 02 October 2020 |
 |
 |
 |
||
| Oostende 02/10/20 | Westerschelde 25/03/18 | Westerschelde 15/12/18 |
|
Name |
ROTRA MARE |
|
Previous names |
2008 Build as: Astrojumper 2008 - 2009 Team Baltic 2009 - 2010 Flintercrown 2010 - 2014 Anne Borchard 2014 - 2016 Flintercrown |
|
Type |
Containership |
|
IMO-number |
9365996 |
|
Call sign |
PBOR |
|
Flag |
The Netherlands |
|
Port of registry |
Werkendam |
|
Previous flags |
02/2009 - 06/2016 The Netherlands, Rotterdam - Call sign: PBOR |
|
GT |
6.564 t |
|
DWT |
Summer: 9.620 t |
|
NT |
3.614 t |
|
Number of 20ft containers |
In hold: 238 On deck: 571 Total: 809 |
|
Container capacity 14t |
238 |
|
Reefer capacity |
150 |
|
Length |
141, 60 m overall 132,30 m between perpendiculars |
|
Breadth |
20,95 m extreme 20,60 m moulder |
|
Draught |
Max: 7,72 m |
|
Air draft |
38,20 m |
|
Freeboard |
1.722 mm |
|
Depth |
9,50 m moulded |
|
Speed |
Max: 19,0 knots |
|
Built |
2009 |
|
Keel laid |
11/2006 |
|
Launch date |
16/06/2007 |
|
Date of completion |
19/02/2009 |
|
Builder |
Nantong Mingde Heavy Industry Stock Co.,Ltd. Tongzhou China Yard number: 2004-47 08/2009 Refit: All Ships Outfitting & Repairs, Krimpen a/d Lek - The Netherlands Yard number: 258 13/10/2021 To dry dock of Royal Niestern Sander to be extended by 11,50 m |
|
Yard number |
258 |
|
Hull material |
Steel |
|
Watertight compartments |
6 |
|
Number of decks |
1 |
|
Main engine |
1x MaK 8M43 - 4 stroke single acting 8 cylinder 430 x 610 mm combustion engine 7.999 kW / 10.868 hp at 500 rpm Starter type: Compressed air Build: 2008 Builder: Caterpillar Motoren GmbH & Co. KG, Rostock - Germany |
|
Propellers |
1x Screw propeller controllable pitch - aft at 158,0 rpm Diameter: 4.600 mm - 5 blades |
|
Boilers |
1 xCHR 162,96 m² - 10,0 bar 1x CHO Wiesloch 28,00 m² - 13,0 bar |
|
Shaft generator |
1x Leroy Somer 1.250 kVA |
|
Generators |
2x Mitsubishi S6R2-MPTK main diesel generatorsets each 707 kVA - 566 kW - 808 hp at 1.200 rpm Build: 2008 Builder: Mitsubishi Heavy Industries Ltd. |
|
Emergency generator |
1x Mitsubishi diesel generatorset 224 kVA - 179 kW - 296 hp Build: 2008 at 1.800 rpm Builder: Mitsubishi Heavy Industries Ltd. |
|
Compressed air receivers |
2x Receivers - 30,0 bar 750 litres |
|
Bow thruster |
1x Controllable pitch thruster 750 kW / 1.020 hp, forward |
|
Number of holds |
3 |
|
Hold ventilation |
6x Air-changes/h |
|
Tank capacities |
Ballast water: 3.800 m³ Potable water: 110 m³ Fuel: 1.425 m³ |
|
Manager |
Shipowners Support B.V. Abel Tasmanplein 4 9934 GD Delfzijl The Netherlands |
|
Previous managers |
02/2006 - 06/2016 Flinter Management B.V., Barendrecht, - The Netherlands |
|
Operator |
Deugro - Siemens (cooperation in Offshore Wind Logistics) Denmark |
|
Registered owner |
SP Vessel 2 BV Care of Shipowners Support BV Abel Tasmanplein 4 9934 GD Delfzijl The Netherlands. |
|
Previous names & owners |
02/2009 - 06/2010 Flintercrown - Flintercrown B.V., Rotterdam - The Netherlands 06/2010 - 01/2014 Anne Borchard - Flintercrown B.V., Rotterdam - The Netherlands 01/2014 - 06/2016 Flintercrown - Flintercrown B.V., Rotterdam - The Netherlands |
|
Latest data adjustment |
05 February 2022 |
