| Westerschelde 06 September 2019 |
 |
 |
 |
 |
|
||||
| Westerschelde 06/09/19 | Westerschelde 06/09/19 | Westerschelde 13/09/11 | Westerschelde 13/09/11 | Westerschelde 26/09/12 | ||||
|
Name |
INTERBALLAST III |
|
Previous names |
1981 Originally built under the name Achille 1989 Achille Elle 1989 Cor El Marina 1999 Interballast III |
|
Type |
Trailing suction hopper dredger |
|
Special service |
Oil recovery ship |
|
IMO-number |
8113463 |
|
Call sign |
PDKO |
|
Flag |
The Netherlands |
|
Port of registry |
Sas Van Gent |
|
GT |
1.670 t |
|
DWT |
Summer: 3.792 t Dredging: 2.300 t |
|
NT |
916 t |
|
Length |
69,89 m overall 65,30 m between perpendiculars |
|
Breadth |
13,26 m |
|
Draught |
Full summer: 5,40 m Full dredging 5,90 m Empty 3,00 m |
|
Depth |
6,40 m |
|
Speed |
12,0 knots |
|
Built |
1981 Rebuild: 1990 |
|
Date of completion |
01.01.1981 |
|
Builder |
Lucchese Achille Venezia Italy |
|
Yard number |
83 |
|
Hull material |
Steel |
|
Hull type |
Single hull |
|
Watertight compartments |
4 |
|
Continuous decks |
2 |
|
Main engine |
1x Ansaldo - 4 stroke 12 cylinder 320 x 420 mm diesel engine - 1.435 kW / 1.950 hp at 420 rpm Built: 1981 Licence: Ansaldo |
|
Propelling system |
1x Screw propeller solid at 420 rpm |
|
Electrical installation |
Power voltage: 380 V Lighting voltage: 220 V Frequency: 50 Hz |
|
Generators |
1x Diesel generatorset 100 kVA 1x Diesel generatorset 100 kVA 1x Diesel generatorset 165 kVA 1x Harbour diesel generatorset 27 kVA |
|
Bow thruster |
1x Cummins diesel - Output 365 hp |
|
Hopper capacity |
1.886 m³ |
|
Dredging system |
Dredging pump de Groot |
|
Suction pipe |
600 mm |
|
Dredging depth |
45° - 20,00 m |
|
Dredging pump drive |
1.000 hp - Capacity 700 m³/h |
|
Jet pump drive |
Cummins diesel - Output 300 hp |
|
Unloading system |
Self unloader hydraulic / Bottom doors |
|
Oil recovery system |
Rigid sweeping arms 2 Koseq 12,00 m |
|
Oil recovery capacity |
600 m³/h heavy Oil |
|
Tank capacities |
Fuel oil: 165 m³ Ballast water: 41 m³ Fresh rinsing water: 30 m³ |
|
Accommodation |
For 9 persons |
|
Group |
Group De Cloedt Aggregates - Environment - Dredging - Concrete Gachardstraat 88 B12 1050 Brussel Belgium |
|
Previous owners |
Versloot Zandzuig- en Transportbedrijf BV |
|
Registered owner |
Interballast I B.V. Wervenweg 14 -15 4551MC Sas van Gent The Netherlands |
