| Zeebrugge 19 May 2010 |
 |
 |
|
| Antwerpen 09/12/15 | Antwezrpen 19/05/10 | |
|
Name |
LANGE WAPPER |
|
Type |
Trailing suction hopper dredger |
|
IMO-number |
9174139 |
|
Call sign |
ORMP |
|
Flag |
Belgium |
|
Port of registry |
Antwerpen |
|
GT |
12.536 t |
|
DWT |
20.642 t |
|
NT |
3.760 t |
|
Length |
129,80 m overall 122,10 m between perpendiculars |
|
Breadth |
26,82 m |
|
Draught |
7,92 m Max.: 9,81 m |
|
Freeboard |
2.903 mm |
|
Depth |
10,80 m moulded |
|
Speed |
14,2 knots |
|
Built |
1999 |
|
Date of completion |
31.05.1999 |
|
Builder |
IHC Merwede Shipyard The Netherlands |
|
Yard number |
676 |
|
Hull material |
Steel |
|
Hull type |
Single hull |
|
Watertight compartments |
7 |
|
Continuous decks |
3 |
|
Main engine |
1x MAN - 4 stroke 12 cylinder 320 x 400 mm internal combustion engine - 11.520 kW / 15.652 hp at 750 rpm Built: 1999 Builder: MAN B&W, Augsburg - Germany |
|
Electrical propulsion gen. |
1x 2.800 kW - 440 Volt |
|
Propulsion |
Sailing: 11.520 kW Trailing: 8.060 kW |
|
Propelling system |
2x Screw propeller controllable pitch |
|
Boilers |
1x CHO 93,00 m² - 10,0 bar |
|
Electrical installation |
Power voltage: 670 V Lighting voltage: 220 V Frequency: 60 Hz |
|
Generators |
1x Diesel generatorset 1.685 kVA - 1.348 kW - 1.935 hp |
|
Emergency generators |
1x Diesel generatorset 897 kVA - 718 kW - 1.033 hp |
|
Total installed power |
13.860 kW With DRACULA: 14.976 kW |
|
Power on pumps |
Dredging: 3.200 kW Shore delivery: 5.520 kW |
|
Hopper capacity |
13.700 m³ |
|
Loading capacity |
20.333 t |
|
Suction pipe |
1x 1.200 mm |
|
Dredging depth |
28,00 m 41,00 m 50,00 m |
|
Discharge pipe |
1x 1.000 mm |
|
Crew |
21 |
|
Manager |
DEME - Dredging, Environmental & Marine Engineering Haven 1025 Schededijk 30 |
|
Group |
DEME - Dredging, Environmental & Marine Engineering Haven 1025 Schededijk 30 |
|
Owner |
Dredging International N.V. & Baggerwerken Decloedt & Zoon N.V. |
