| Westerschelde 06 March 2020 |
|
Name |
NAVIGATOR GEMINI |
|
Type |
Liquefied gas tanker - LPG |
|
IMO-number |
9404780 |
|
Call sign |
A8RD9 |
|
Flag |
Liberia |
|
Port of registry |
Monrovia |
|
GT |
18.311 t |
|
DWT |
23.317 t |
|
NT |
5.493 t |
|
Length |
159,97 m overall 152,20 m between perpendiculars |
|
Breadth |
26,62 m extreme |
|
Draught |
Summer: 10,92 m |
|
Keel to mast end |
44,75 m |
|
Depth |
16,40 m |
|
Speed |
Max: 16,0 knots |
|
Built |
2009 |
|
Keel laid |
11/11/2008 |
|
Launch date |
13/01/2009 |
|
Date of completion |
16/03/2009 |
|
Builder |
Hyundai Mipo Dockyard Co., Ltd. Ulsan South Korea |
|
Yard number |
8007 |
|
Hull material |
Steel |
|
Hull type |
Single hull Double bottom |
|
Main engine |
1x MAN-B&W S46MC-C - 2 stroke 6 cylinder 460 w 1.932 mm combustion engine 7.860 kW / 10.689 bhp at 129,0 rpm |
|
Propellers |
1x Fixed pitch mono-block propeller |
|
Boilers |
1x Auxiliary boiler, oil/gas fired |
|
Generators |
3x Hyundai 5H21/32 main diesel generatorsets |
|
Emergency generator |
1x Cummins 6CT-8.3-D(M) diesel generatorset |
|
Number of tanks |
4x Bi-lobe - Independent Type C (-48°C; 5,3 bar) 2x Deck tank 155 m³ (-48°C; 18.2 Bar) |
|
Cargo tank capacity |
Liquid: 20.365 m³ |
|
Number of pumps |
8x Cargo pumps each 250 m³/h |
|
Tank capacities |
HFO: 1.590 m³ MGO: 268 m³ Ballast: 9.193,9 m³ |
|
Anchor equipment |
Length: 605,00 m Diameter: 62 mm |
|
ISM & commercial manager |
Navigator Gas Ship Management (Denmark) ApS Smakkedalen 4 2820 Gentofte Denmark |
|
Registered owner |
Navigator Gemini LLC The Verde, 10 Bressenden Place London SW1E5DH United Kingdom |
|
Latest data adjustment |
16 January 2023 |
