| Westerschelde 13 June 2019 |
 |
 |
 |
 |
|||
| Antwerpen 24/04/13 | Westerschelde 07/04/14 | Westerschelde 06/09/20 | Westerschelde 03/03/17 |
|||
|
Name |
GAS CERBERUS |
|
Type |
Liquefied gas carrier - LPG |
|
IMO-number |
9507740 |
|
Call sign |
A8YQ2 |
|
Flag |
Liberia |
|
Port of registry |
Monrovia |
|
GT |
4.312 t registered Suez: 4.986,64 t |
|
DWT |
Summer: 5.002 t |
|
NT |
1.381 t registered Suez: 4.016,51 t Panama: 3.682,35 t |
|
Displacement |
7.739 t |
|
Length |
99,90 m overall 93,50 m between perpendiculars |
|
Breadth |
17,60 m moulded |
|
Draught |
Summer: 6,15 m |
|
Keel to mast end |
33,67 m |
|
Freeboard |
1.868 mm |
|
Depth |
8,00 m moulded |
|
Speed |
Max: 15,0 knots Servixe: 13,0 knots |
|
Built |
2011 |
|
Keel laid |
31/08/2010 |
|
Launch date |
01/12/2010 |
|
Date of completion |
20/04/2011 |
|
Builder |
Kanrei Shipbuilding Co., Ltd. 676 Satoura-Cho Satoura Aza Ebisu Naruto-City Tokushima Pref. 772-0021, Naruto-City, 772-0021 Japan |
|
Yard number |
K423 |
|
Hull material |
Ordinary strength steel |
|
Hull type |
Double hull |
|
Watertight bulkheads |
16 |
|
Main engine |
1x MAN-B&W/Mitsui 5L35MC - 2 stroke 5 cylinder 350 x 1.050 mm combustion engine Mcr 3.250 kW at 210,0 rpm Manufacturer: Makita Corporation - Japan |
|
Propellers |
1x Manufacturer: Nakashima Propeller Co., Ltd. |
|
Boilers |
1x Unfired exhaust gas boiler KF-91F - 14,0 bar Evaporation: 380 Kg/h 1x Fired boiler type Miura Z boiler VWH-600E- 7,0 bar Evaporation: 538 Kg/h Manufacturer: Miura Co., Ltd. |
|
Generators |
2x Yanmar 6NY16L-SN - 4 stroke 6 cylinder diesel engine each 400 kW at 1.200 rpm connected with 2 generators each 360 kW Manufacturer: Nishishiba Electric Co., Ltd. |
|
Emergency generator |
1x Yanmar NFD-150K diesel generatorset 80 kW |
|
Bow threuster |
1x 250 kW |
|
Cargo tank capacity |
100% Tank 1: 2.509,023 m³ Tank 2: 2.509,214 m³ Total: 5.018,237 m³ 98% Tank 1: 2.458,842 m³ Tank 2: 2.459,029 m³ Total: 4.917,871 m³ |
|
Number of pumps |
2x Deepwell vertical centrifugal cargo pumps each 300 m³/h Builder: Niigata Worthington Co., Ltd. |
|
Cargo lines |
Distance from stern (AP): 50,85 m Distance form stem (FP): 42,65 m Height above deck: 1,07 m for liquid manifold Distance from ship’s rail: 2,50 m Underside keel to manifold: 9,10 m |
|
Fuel oil purifier |
2x Type Mitsubishi SJ20G - Centrifugal Capacity 800 l/h at 98°C |
|
Lub oil purifier |
1x Type Mitsubishi SJ10G - Centrifugal Capacity 800 l/h at 95°C |
|
Number of tanks |
Ballast: 16 Fuel oil: 8 Lubricating oil: 7 Sludge: 5 Diesel oil: 4 Chain: 2 Fresh water: 2 Waste water: 2 |
|
Tank capacities |
Diesel oil: 126,90 m³ Fresh water: 212,38 m³ Fuel oil: 493,23 m³ Lube oil: 63,50 m³ Tank ballast: 2.085,12 m³ |
|
Maximum cargo pressure |
17,65 bar |
|
Lifting equipment |
1x Hose handling crane - SWL 4,0 t Manufacturer: Kyoritsu Kikai Co., Ltd. 1x Provision Davit - SWL 9,0 t 1x Trolley hoist - SWL 2,0 t Manufacturer: Futaba Mfg.,Co., Ltd. |
|
ISM & commercial manager |
Stealth Maritime Corp Sa. 331, Kifisias Avenue Kifisia, 145 61 Athens Greece |
|
Registered owner |
Carinthia Inc.; Monrovia - Liberia Care of Stealth Maritime Corp SA , 331, Kifisias Avenue Kifisia, 145 61 Athens Greece |
|
Registered owner |
Carinthia Inc. |
|
Latest dat adjustment |
31 December 2022 |
