| Zeebrugge 02 August 2011 |
 |
| Zeebrugge 02/08/11 |
|
Name |
GAS KAIZEN |
|
Previous names |
1991 Fernando Clariana 2004 Gas Courchevel |
|
Type |
Liquefied gas tanker |
|
IMO-number |
8818817 |
|
Call sign |
V7GZ6 |
|
Flag |
Marshall Islands |
|
Port of registry |
Majuro |
|
GT |
4.691 t registered Suez: 5.140,69 t Panama: 5.302,10 t |
|
DWT |
4.380 t |
|
NT |
1.407 t registered Suez: 3.677,14 t Panama: 3.203,86 t |
|
Light weight |
2.760,82 t |
|
Length |
104,48 m overall 97,55 m between perpendiculars |
|
Breadth |
15,10 m |
|
Draught |
Summer: 6,11 m |
|
Freeboard |
3.860 mm |
|
Depth |
9,95 m |
|
Speed |
15,4 knots |
|
Built |
1991 |
|
Date of completion |
19.07.1991 |
|
Builder |
Juliana Constructora Gijonesa |
|
Yard number |
341 |
|
Hull material |
Steel |
|
Hull type |
Double bottom |
|
Watertight compartments |
6 |
|
Continuous decks |
1 |
|
Main engine |
1x Wärtsilä 8 R 32 D - 4 stroke 8 cylinder 320 x 350 mm internal combustion engine - 2.960 kW / 4.025 bhp at 720 rpm Built: 1990 |
|
Electrical propulsion gen. |
1x 480 kW |
|
Propelling system |
1x Screw propeller controllable pitch at 132 rpm |
|
Boiler |
1x CHM Composite auxiliary boiler (oil fired/exhaust gas) Clarka Capman 96,00 m² - 7,5 bar |
|
Electrical installation |
Power voltage: 440 V Lighting voltage: 220 V Frequency: 60 Hz |
|
Generators |
3x Wärtsilä 4 R 22 HF-C diesel generatorsets each 429 kVA - 343 kW - 547 hp |
|
Bow thruster |
1x Eimar Weir 1.934-Z - 184 kW |
|
Number of tanks |
3 |
|
Total capacity of tanks |
Tank 1: 1.516,58 m³ Tank 2: 584,73 m³ Tank 3: 2.0085,51 m³ Total: 4.109,82 m³ |
|
Tanks |
Max. pressure: 7,0 bar Minimum temperature: -48.0 °C Valve setting: 0,5 / 1,5 / 4,85 / 7,0 bar |
|
Loading rate |
555 m³/h |
|
Cargo pumps |
5x Deepwell Kvaerner Eureka - 220 m³/h 1x Booster pump Kvaerner Eureka - 220 m³/h |
|
Cargo compressor |
3x Sulzer 2K-145-2F each 400 m³/h Make: Sulzer - Germany |
|
Transport type |
Refrigerated Semi-Refrigerated |
|
Fuel capacity |
529 m³ |
|
Lifting equipment |
2x Cranes - SWL 3,0 t each |
|
Crew |
15 |
|
Operator |
Stealth Maritime Corporation S.A. |
|
Owner |
Geneve Butane Inc. |
|
Scrapped |
03.2015 sold to scarp yard Chittagong - Bangladesh |
|
Latest data adjustment |
02 April 2015 |
