| Zeebrugge 01 June 2005 |
|
Name |
LINDA KOSAN |
|
Type |
Liquefied Gas Tanker |
|
IMO-number |
9034511 |
|
Call sign |
VSTI5 |
|
Flag |
Isle of Man |
|
GT |
2.223 t |
|
DWT |
2.004 t |
|
NT |
666 t |
|
Length |
73,60 m overall |
|
Breadth |
14,02 m |
|
Draught |
Summer: 4,96 m |
|
Air draft |
21,90 m ballast |
|
Depth |
6,10 m |
|
Speed |
12,5 knots |
|
Built |
1992 |
|
Date of completion |
08.10.1992 |
|
Builder |
Hermann Surken |
|
Yard number |
376 |
|
Hull material |
Steel |
|
Hull type |
Double hull |
|
Watertight compartments |
6 |
|
Continuous decks |
2 |
|
Main engine |
1x MAN-B&W - 4 stroke 6 cylinder 280 x 320 mm internal combustion engine - 1.470 kW / 1.997 hp at 775 rpm Built: 1992 |
|
Electrical propulsion gen. |
1x 388 kW |
|
Propelling system |
1x Screw propeller controllable pitch at 201 rpm |
|
Electrical installation |
Power voltage: 440 V Lighting voltage: 220 V Frequency: 60 Hz |
|
Generators |
3x Diesel generatorsets each 243 kVA - 194 kW - 289 hp |
|
Bow thruster |
220 kW |
|
Number of cargo tanks |
2 |
|
Tank volume at 100% |
Tank 1: 1.133,72 m³ |
|
Minimum temperature |
-48°C |
|
Tank max. pressure |
7,5 Bar |
|
Max. cargo density |
0,97 t/m³ |
|
Transport type |
Refrigerated |
|
Deepwell pumps |
2x Each 220 m³/h |
|
Booster pump |
1x On deck - 300 m³/h |
|
Fuel capacity |
343 m³ |
|
Company |
Lauritzen Kosan S/A |
|
Renamed |
10.2006 Sigas Linda |
