Linda Kosan
Zeebrugge 01 June 2005



Name

LINDA KOSAN

Type

Liquefied Gas Tanker

IMO-number

9034511

Call sign

VSTI5

Flag

Isle of Man

GT

2.223 t

DWT

2.004 t

NT

666 t

Length

73,60 m overall
66,55 m between perpendiculars

Breadth

14,02 m

Draught

Summer: 4,96 m

Air draft

21,90 m ballast

Depth

6,10 m

Speed

12,5 knots

Built

1992

Date of completion

08.10.1992

Builder

Hermann Surken
Papenburg
Germany

Yard number

376

Hull material

Steel

Hull type

Double hull

Watertight compartments

6

Continuous decks

2

Main engine

1x MAN-B&W - 4 stroke 6 cylinder 280 x 320 mm internal combustion engine - 1.470 kW / 1.997 hp at 775 rpm

Built: 1992

Electrical propulsion gen.

1x 388 kW

Propelling system

1x Screw propeller controllable pitch at 201 rpm

Electrical installation

Power voltage: 440 V

Lighting voltage: 220 V

Frequency: 60 Hz

Generators

3x Diesel generatorsets each 243 kVA - 194 kW - 289 hp

Bow thruster

220 kW

Number of cargo tanks

2

Tank volume at 100%

Tank 1: 1.133,72 m³
Tank 2: 626,17 m³
Total: 1.759,89 m³

Minimum temperature

-48°C

Tank max. pressure

7,5 Bar

Max. cargo density

0,97 t/m³

Transport type

Refrigerated
Semi-Refrigerated

Deepwell pumps

2x Each 220 m³/h

Booster pump

1x On deck - 300 m³/h

Fuel capacity

343 m³

Company

Lauritzen Kosan S/A
28 Sankt Annae Plads
1291 Copenhagen K
Denmark

Renamed

10.2006 Sigas Linda
