Lingegas
Zeebrugge 09 May 2004



Name

LINGEGAS

Type

Liquefied gas tanker

IMO-number

8008383

Call sign

PJKZ

Flag

Netherlands Antilles

Port of registration

Willemstad

GT

2.712 t

DWT

3.403 t

NT

813 t

Length

82,56 m overall
75,00 m between perpendiculars

74,95 m m registered

Breadth

14,10 m

Draught

Summer: 6,51 m

Forecastle

17,80 m

Depth

9,02 m

Speed

13,5 knots

Built

1981

Keel laid

28.04.1980

Launch date

27.02.1981

Date of completion

27.05.1981

Builder

B.V. Scheepswerf Waterhuizen J. Pattje
Waterhuizen 7
9609 PA Waterhuizen
The Netherlands

Yard number

345

Hull type

Double bottom

Watertight bulkheads

5

Continuous decks

1

Main Engine

1x Deutz SBV 6 M 540 - 4 stroke single acting 6 cylinder 370 x 400 mm diesel engine - 1.839 kW at 550 rpm

Built: 1980

Builder: Klöckner-Humboldt-Deutz AG
51057 Köln
Federal Republic of Germany

Number of screws

1x Solid propeller (keyless) - aft at 179 rpm

Boiler

1x Thermal oil heater, oil fired - 10,0 bar

Heating surface: 29,8 m²

Year of manufacture: 1980

Electric installations

1x Plant 440 V - 857,5 kVA

1x Plant 24 V - 15,2 kW

Shaft generator

1x 287.5 kVA

Generators

2x Main diesel generatorsets each 285 kVA

Emergency generator

1x Diesel generatorset 15,2 kW

Compressed air receivers

2x Receivers each 500 litres - 30,0 bar

1x Receiver 30 litres - 30,0 bar

1x Receiver 500 litres - 11,0 bar

Number of cargo tanks

2

Liquid cargo

3.232 m³

Largest cargo tank

1.757 m³

Tank capacities

Ballast water: 1.359 m³

Fuel oil: 239 m³

Anchor equipment

3x Anchors weight each 2.100 kg

Anchor chain: 440,00 m

Lifting equipment

1x Crane - SWL 2,4 t

Manager

Sloman Neptun Schiffahrts-A.G
Germany

Shipping company

Anthony Veder Rederijzaken B.V.
The Netherlands

Owner

Lingegas Shipping N.V
Willemstad
Netherlands Antilles

Renamed

2007 Ingegas

Scrapped

11.2013

Last update

10 December 2013
