Westerschelde 14 August 2018 |
 |
 |
 |
 |
 |
 |
|||||
| Westerschelde 14/08/18 | Westerschelde 14/08/18 | Westerschelde 17/03/16 | Zeebrugge 24/01/14 | Zeebrugge 24/01/14 | Zeebrugge 24/01/14 | |||||
 |
 |
|||||||||
| Westerschelde 20/04/16 | Westerschelde 19/07/17 | |||||||||
|
Name |
FORBIN |
|
Type |
Liquefied gas tanker |
|
Main products |
Butane - Liquefied petroleum gases - Vinyl-Chloride monomer |
|
IMO-number |
9559652 |
|
Call sign |
9HA2597 |
|
Flag |
Malta |
|
Port of registry |
Valletta |
|
GT |
4.313 t |
|
DWT |
Summer: 5.072,36 t |
|
NT |
1.374 t |
|
Length |
99,90 m overall 93,51 m between perpendiculars |
|
Breadth |
17,60 m |
|
Draught |
Summer: 6,27 m |
|
Keel to mast end |
31,60 m |
|
Freeboard |
1.768 mm |
|
Depth |
8,00 m |
|
Speed |
13,0 knots |
|
Built |
2011 |
|
Date of completion |
11/01/2011 |
|
Builder |
Kanrei Shipbuilding Co., Ltd. Naruto Japan |
|
Yard number |
418 |
|
Hull material |
Ordinary strength steel |
|
Hull type |
Double hull |
|
Watertight compartments |
16 |
|
Continuous decks |
1 |
|
Main engine |
1x MAN-B&W/Makita 5L35MC - 2 stroke 5 cylinder 350 x 1.050 mm combustion engine 3.252 kW / 4.421 hp at 210 rpm Built: 08/06/2010 Builder: Makita Corporation, Amagasaki - Japan |
|
Propellers |
1x Fixed pitch propeller - aft at 210 rpm |
|
Boilers |
1x CHO Miura 7,20 m² - 0,70 bar 1x CHR Miura 91,40 m² - 1,40 bar |
|
Generators |
3x Yanmar 6NY16L-SN main diesel generatorsets each 450 kVA - 360 kW - 544 hp / 3 phase 445 Volt - 60 Hz |
|
Emergency generator |
1x Yanmar diesel NFD-150K diesel generatorset 100 kVA - 80 kW - 135 hp |
|
Bow thruster |
1x 250 kW |
|
Number of tanks |
2 |
|
Cargo tank capacity 100% |
Tank 1:2.509,02 m³ Tank 2: 2.509,21 Total: 5.018,23 m³ |
|
Number of pumps |
2x Deepwell type of vertical centrifugal cargo pumps each 250 m³/h Builder: Niigata Worthington Co.,Ltd. |
|
Transport type |
Pressure |
|
Tank pressure |
17,65 barg |
|
Tank temperature |
0°C |
|
Tank capacities |
Diesel Oil: 126,90 m³ Freshwater: 212,38 m³ Fuel Oil: 493,23 m³ Lube Oil: 63,50 m³ Tank Ballast: 2.085,12 m³ |
|
Lifting capacity |
1x Provision davit - SWL 0,9.t 1x Futaba trolley hoist - SWL 2,0 t 1x Kyoritsu Kika Hose handling crane - SWL 4,0 tons @ 10 m/min, radius: 15,00 m |
|
Crew size |
20 |
|
Commercial manager |
Geogas Trading S.A 28 Boulevard du Pont-d'Arve 1205 Geneva Switzerland |
|
ISM manager |
V Ships France SAS 34, Place Viarme, 4 4000 Nantes France |
|
Operator |
V Ships France SAS |
|
Registered owner |
Geogas Maritime SAS 209, rue de l'Universite 75007 Paris France |
|
Last data update |
31 July 2023 |
