Malaga, Spain 06 October 2020 |
|
Name |
MAIA |
|
Previous names |
2009 - 02/2013 Valeria Della Gatta |
|
Type |
Kamsarmax gearless bulk carrier - Strengthened for heavy cargo loading |
|
IMO-number |
9422938 |
|
Call sign |
V7AP2 |
|
Flag |
Marshall Islands |
|
Port of registry |
Majuro |
|
Previous flags |
2009 - 2013 Italy - Call sign: IBWA |
|
GT |
42.930 t registered |
|
DWT |
Summer: 82.193 t |
|
NT |
27.324 t registered |
|
Length |
228,99 m overall |
|
Breadth |
32,26 m moulded |
|
Draught |
Summer: 14,43 m |
|
Moulded L x B x D |
222,00 x 32,26 x 20,05 m |
|
Registered L x B x D |
222,54 x 32,26 x 20,05 m |
|
Freeboard |
Summer: 5.674 mm |
|
Depth |
20,05 m moulded |
|
Speed |
Service: 14,0 knots Max: 15,4 knots |
|
Built |
2009 |
|
Keel laid |
28/04/2009 |
|
Launch date |
25/09/2009 |
|
Delivery date |
25/08/2009 |
|
Builder |
Tsuneishi Shipbuilding Co., Ltd. Fukuyama Japan |
|
Yard number |
1435 |
|
Hull material |
Steel |
|
Hull type |
Single hull |
|
Watertight compartments |
10 |
|
Continuous decks |
1 |
|
Main engine |
1x Mitsui/MAN-B&W 6S60MC-C - 2 stroke single acting 6 cylinder 600 x 2.400 mm combustion engine 9.710 kW at 97,4 rpm Builder: Mitsui Engineering & Shipbuilding Co., Ltd. Tamano Works |
|
Propeller shaft |
1x Oil lubrication shaft without monitoring device Diameter: 560 mm |
|
Propellers |
1x Fixed pitch propeller |
|
Boilers |
1x Auxiliary vertical boiler - 7,0 bar Evaporation: 2,22 t/h Manufacturer: Osaka Boiler MFG. Co. Ltd. |
|
Generators |
3x Main diesel generatorsets each 400 kW Manufacturer: Nishishiba Electric Co., Ltd. |
|
Number of holds |
7 6x Holds for cargo 1x Hold cargo or ballast water |
|
Cargo hold capacity |
Grain: 97.294 m³ Bale: 97.294 m³ |
|
Number of hatches |
7 1x 14,20 x 13,80 m 6x 17,80 x 15,40 m |
|
Hatches type |
Mac Gregor side rolling-twin panel |
|
Tank capacities |
Fuel oil: 3.186 m³ Fresh water: 468 m³ Water ballast: 22.612 t |
|
Crew size |
22 |
|
Manager |
Diana Shipping Inc. c/o Diana Shipping Services S.A. Pendelis 16 175 64 Palaio Faliro Athens, Greece |
|
Registered owner |
Jabat Shipping Company Inc. |
|
Previous names & owners |
2009 - 02/2013 Valeria Della Gatta - Deiulemar Navigazione SpA |
|
Latest data adjustment |
20 November 2020 |
