Westerschelde 14 February 2020 |
|
Name |
ANNA |
|
Type |
General cargo ship - Heavycargo - Equipped for carriage of containers |
|
IMO-number |
9566796 |
|
Call sign |
ZDKC9 |
|
Flag |
Gibraltar |
|
Port of registry |
Gibraltar |
|
GT |
5.044 t |
|
DWT |
Summer: 7.712 t |
|
NT |
2.718 t |
|
Number of 20ft containers |
In holds: 162 On deck: 144 Total: 306 |
|
Length |
125,79 m overall 119,53 m between perpendiculars |
|
Breadth |
14,40 m |
|
Draught |
Summer: 6,50 m |
|
Freeboard |
1.609 mm |
|
Depth |
8,31 m |
|
Speed |
13,0 knots |
|
Built |
2011 |
|
Date of completion |
03/05/2001 |
|
Builder |
Jiangsu Yangzi Changbo Shipbuilding Co.,Ltd. China |
|
Yard number |
CBSY07-012 |
|
Hull material |
Steel |
|
Watertight compartments |
5 |
|
Movable bulkheads |
2x Movable bulkheads also to be suitable for tweendeck |
|
Continuous decks |
1 |
|
Main engine |
1x MaK 9M25C - 4 stroke 9 cylinder 255 x 400 mm combustion engine 2.970 kW / 4.035 hp at 750 rpm |
|
Propellers |
1x Screw propeller controllable pitch - aft at 194,0 rpm |
|
Boilers |
1x CHO Heatmaster 12,24 m² - 10,0 bar 1x CHR Heatmaster 49,43 m² - 10,0 bar |
|
Shaft generator |
1X 424 eKW |
|
Generators |
2x Main diesel generatorsets each 235 kVA - 188 kW - 340 hp |
|
Emergency generator |
1x Diesel generatorset 96 ekW |
|
Bow thruster |
1x Fixed pitch thruster 350 kW |
|
Number of holds |
2 Hold 1: 42,30 x 11,70 m Hold 2: 51,40 x 11,70 m |
|
Hold capacity |
Hold 1:4.313 m³ Hold 2: 5.415 m³ Total: 9.728 m³ / 343.556 ft³ |
|
Hold ventilation |
6x Air-changes per hour |
|
Max permitted loads |
Tanktop: 14,0 t/m² Hatch covers: 1,6 t/m² Tweendeck: 2,5 t/m² |
|
Tank capacities |
HFO abt.: 365 m³ MDO abt.: 89 m³ Fresh water abt.: 68 m³ Ballast water abt.: 3.275 m³ |
|
Lifting equipment |
1 Gantry crane - SWL 15,0 t for opening cargo hold and handling of tweendeck |
|
Crew size |
11 |
|
Commercial manager |
Briese Shipping BV Torenstraat 14 9679 BP Scheemda The Netherlands |
|
ISM manager |
Briese Dry Cargo GmbH & Co., KG Hafenstrasse 12 26789 Leer Germany |
|
Registered owner |
Oldersum Shipping Company Limited Care of Briese Shipping BV Torenstraat 14 9679 BP Scheemda The Netherlands |
|
Latest data adjustment |
11 November 2021 |
