Name |
LUZON STRAIT |
|
Previous names |
2002 - 2002 Tiger Max |
|
Type |
Refrigerated cargo ship |
|
IMO-number |
9204960 |
|
Call sign |
D5WC5 |
|
Flag |
Liberia |
|
Port of registry |
Monrovia |
|
Previous flags |
07/2002 - 02/2006 The Netherlands, Groningen - Call sign: PBHT 02/2006 - 11/2015 Liberia, Monrovia - Call sign: A8IO4 11/2015 - 02/2020 Malta, Valletta - Call sign: 9HA3803 |
|
GT |
14.413 t |
|
DWT |
15.917 t |
|
NT |
7.536 t Panama: 12.563 t Suez: 12.848,07 t |
|
Number of 20ft containers |
On deck: 440 |
|
Reefer plugs |
206 |
|
Length |
167,00 m overall 156,17 m between perpendiculars |
|
Breadth |
25,00 m |
|
Draught |
Max: 9,31 m |
|
Freeboard |
3.411 mm |
|
Depth |
13,40 m |
|
Speed |
Ballast: 22,0 knots Banana laden: 21,5 knots Banana laden + containers: 20,5 knots |
|
Built |
2002 |
|
Date of completion |
22/08/2002 |
|
Builder |
China Shipbuilding Corporation Ltd. Keelung Taiwan |
|
Yard number |
730 |
|
Hull material |
Steel |
|
Watertight compartments |
7 |
|
Continuous decks |
4 |
|
Main engine |
1x MAN-B&W/ Hyundai 7S60MC-C - 2 stroke single acting 7 cylinder 600 x 2.292 mm combustion engine 15.512 kW / 21.447 hp at 105,0 rpm Manufacturer: Hyundai Heavy Industries Co. Ltd., Ulsan - South Korea |
|
Propellers |
1x Fixed pitch propeller - aft at 105,0 rpm |
|
Boilers |
1x CHO Aalborg 235,60 m² - 7,0 bar |
|
Electric installations |
Power voltage: 450 V Lighting voltage: 110 V Frequency: 60 Hz |
|
Generators |
4x Main diesel generatorsets each 1.875 kVA - 1.500 kW - 2.198 hp |
|
Emergency generator |
1x Diesel generatorset 124 kVA - 99 kW - 148 hp |
|
Bow thruster |
1x 770 kW |
|
Number of holds |
4 Hold 1: 89.931 ft³ Hold 2: 160.576 ft² Hold 3: 212.967 ft³ Hold 4: 162.537 ft³ Total: 626,011 ft³ / 17.726,65 m³ |
|
Reefer capacity |
17.726 m³ |
|
Reefer cargo space |
7.340,55 m² |
|
Number of hatches |
4 6,20 x 3,90 m each |
|
Compartments |
15 |
|
Temperature zones |
8 |
|
Pallets |
9.681 |
|
Minimum deck height |
2,25 m |
|
Tank capacities 100% |
IFO380: 2.017 m³ MGO: 223 m³ |
|
Lifting equipment |
4x Sideloaders each 12,5 t |
|
Cargo gear |
2w Deck cranes - WSL 45,0 t each |
|
Manager |
Seatrade Groningen BV Leonard Springerlaan 17 9727 KB Groningen The Netherlands |
|
Previous managers |
07/2002 - 02/2006 Seatrade Groningen B.V., Groningen - The Netherlands 02/2006 - 02/2020 Triton Schiffahrts G.m.b.H. & Co. K.G., Leer - Germany |
|
Chartered |
Geest Line Eaglepoint Little Park Farm Road Fareham PO15 5TD United kingdom |
|
Registered owner |
Marea Ships Ltd. - Monrovia, Liberia Care of Seatrade Groningen BV Leonard Springerlaan 17 9727 KB Groningen The Netherlands |
|
Previous owners |
07/2002 - 02/2006 B.V. Shipping Company Luzon Strait, Groningen - The Netherlands 02/2006 - 02/2020 Luzon Strait Schiffahrtsgesellschaft m.b.H. & Co. K.G., Leer - Germany |
|
Latest data adjustment |
02 December 2021 |
