| Westerschelde 22 Jult 2020 |
|
Name |
SANDOE |
|
Previous names |
12/2000 - 11/2005 Morgenstond III 11/2005 - 10/2019 Emsmoon 10/2019 - 11/2019 Helas |
|
Type |
Multi-purpose dry cargo ship - Equipped for carriage of containers - singledecker |
|
IMO-number |
9213894 |
|
Call sign |
5BJE5 |
|
Flag |
Cyprus |
|
Port of registry |
Limassol |
|
Previous flags |
12/2000 - 11/2005 The Netherlands, Siddeburen - Call sign: PBAX 11/2005 - 10/2019 Antigua & Barbuda, St. John’s - Call sign: V2BN3 |
|
GT |
4.563 t |
|
DWT |
7.041 t |
|
NT |
2.613 t |
|
Number of 20ft containers |
356 |
|
Length |
111,75 m overall 105,34 m between perpendiculars |
|
Breadth |
14,95 m moulded |
|
Draught |
Summer: 6,86 m Winter: 6,71 m |
|
Air draft |
29,50 m |
|
Depth |
8,40 m to main deck |
|
Speed |
14,2 knots |
|
Built |
2000 |
|
Keel laid |
29/06/1998 |
|
Launch date |
18/11/2000 |
|
Date of completion |
14/12/2000 |
|
Builder |
Ferus Smit Leer GmbH Leer Germany |
|
Yard number |
326 |
|
Hull material |
Shipbuilding steel (standard) |
|
Hull type |
Single hull partly double bottom (e.g. interrupted in way of machinery space) |
|
Watertight bulkheads |
4 |
|
Watertight compartments |
6 |
|
Continuous decks |
1 |
|
Main engine |
1x Wärtsilä 8R32E - 4 stroke single acting 8 cylinder 320 x 350 mm combustion engine 3.280 kW at 750 rpm Builder: Wärtsilä NSD Finland OY, Vaasa/Vasa - Finland |
|
Propellers |
1x Screw propeller controllable pitch - aft at 159 rpm |
|
Boilers |
1x CHO Gekakonus 1,00 m² - 10,0 bar 1x CHR Gekakonus 1,00 m² - 10,0 bar |
|
Electric installations |
1x Plant 400 V - 187,5 kVA 1x Plant 400 V - 187,5 kVA 1x Plant 400 V - 565 kVA 1x Plant 400 V - 106,3 kVA |
|
Shaft generator |
1x 565 kVA |
|
Generators |
2x Sisu 645 DSBIMG main diesel generators each 187,5 kVA |
|
Emergency & harbour gen. |
1x Sisu 20 DSG diesel generator 106,3 kVA |
|
Compressed air receivers |
2x Receivers each 250 litres - 30,0 bar |
|
Bow thruster |
1x 350 kW |
|
Number of holds |
2 Hold 1: 27,30 x 12,60 m Hold 2: 53.70 x 12.60 m |
|
Cargo hold capacity |
Grain: 9.052 m³ Bale: 8.620 m³ |
|
Hold ventilation |
6x Air-changes per hour |
|
Number of hatches |
2 Hatch 1: 27,30 x 12,60 m Hatch 2: 53,70 x 12,60 m |
|
Max permitted loads |
Hatch covers: 1,75 t/m² |
|
Tank capacities |
Bunker: 450 t Fuel: 450 t Ballast: 2.584,7 m³ |
|
Anchor equipment |
3x Anchors weight each 3.060 kg Chain Length: 495,00 m Diameter: 44 mm |
|
Crew size |
9 |
|
Manager |
Lohmann Bereederungen G.m.b.H. & Co. K.G. Boschstraße 15 49733 Haren (Ems) Germany |
|
Previous managers |
12/200 - 11/2005 Wagenborg Shipping B.V., Delfzijl - The Netherlands 11/2005 - 10/2019 Marlow Ship Management, Hamburg - Germany |
|
Registered owner |
Hermann Lohmann Schifffahrt G.m.b.H. & Co. KG, Haren/Ems Germany |
|
Previous names & owners |
12/200 - 11/2005 Morgenstond III - C.V. Scheepvaartonderneming Morgenstond III, Siddeburen - The Netherlands 11/2005 - 10/2019 Emsmoon - Emsmoon NTH Schiffahrts, Papenburg-Ems - Germany |
|
Renamed |
12/2020 Helas Cyprus, Limassol - Call sign: 5BJE5 Manager: Lohmann Bereederungen G.m.b.H. & Co. K.G., Haren/Ems - Germany Owner: Hermann Lohmann Schifffahrt G.m.b.H. & Co. KG, Haren/Ems - Germany |
|
Latest data adjustment |
18 April 2022 |
