| Westerschelde 03 August 2019 |
|
Name |
MODEST SW |
|
Previous names |
2012 - 2018 Botafogo SW |
|
Type |
Bulk carrier - Strengthened for heavy cargo loading |
|
IMO-number |
9476941 |
|
Call sign |
3FIG8 |
|
Flag |
Republic of Panama |
|
Port of registry |
Panama City |
|
GRT |
40.023 t |
|
DWT |
79.483 t |
|
NRT |
25.300 t |
|
Length |
225,00 m overall |
|
Breadth |
32,26 m moulded |
|
Draught |
Summer: 14,12 m |
|
Moulded L x B x D |
220,00 x 32,26 x 19,39 m |
|
Registered L x B x D |
220,16 x 32,26 x 19,39 m |
|
Keel to mast end |
46,83 m |
|
Freeboard |
Summer: 5.323 mm |
|
Depth |
19,39 m moulded |
|
Speed |
Max: 16,4 knots Service: 14,5 knots |
|
Built |
2012 |
|
Keel laid |
25/11/2009 |
|
Launch date |
13/01/2012 |
|
Date of completion |
22/02/2012 |
|
Builder |
Oshima Shipbuilding Co., Ltd. Saikai Japan |
|
Yard number |
10563 |
|
Hull material |
Steel |
|
Main engine |
2x MAN-B&W/Mitsui 5S60MC-C - 2 stroke single acting 5 cylinder 600 x 2.400 mm combustion engine 9.318 kW / 12.670 hp at 89,4 rpm Manufacturer: Mitsui Engineering & Shipbuilding Co., Ltd. Tamano Works - Japan |
|
Propeller shaft |
1x Oil lubrication shaft without monitoring device Diameter: 530 mm |
|
Propellers |
1x Fixed pitch propeller |
|
Boilers |
1x Auxiliary vertical boiler - 0,69 MPa Evaporation: 2,09 t/h Manufacturer: Osaka Boiler Mfg. Co., Ltd. |
|
Generators |
4x Diesel generatorsets total 1.545 kVA |
|
Number of holds |
7 |
|
Cargo hold capacity |
Bale: 88.029 m³ Grain: 90.009 m² |
|
Tank capacities |
Fuel oil: 2.150 m³ Fresh water: 364 m³ |
|
ISM & commercial manager |
Shih Wei Navigation Co., Ltd. 16th Floor, 167, Fuxing N Road, Songshan District Taipei City, 10547 China, Republic of (Taiwan) |
|
Registered owner |
Modest Pescadores SA - Republic of Panama Care of Shih Wei Navigation Co Ltd , 16th Floor, 167, Fuxing N Road, Songshan District Taipei City, 10547 China, Republic of (Taiwan) |
|
Latest data adjustment |
26 November 2022 |
