| Westerschelde 05 May 2018 |
|
Name |
EEMS SEA |
|
Previous names |
Build as: Eems Space |
|
Type |
General cargo ship - Strengthened for heavy cargoes |
|
IMO-number |
9503536 |
|
Call sign |
PHPM |
|
Flag |
The Netherlands |
|
Port of registry |
Delfzijl |
|
GT |
2.153 t |
|
DWT |
3.410 t t |
|
DWCC |
Summer: 3.250 t Winter: 3.150 t |
|
NT |
1.121 t |
|
Length |
99,27 m overall 95,74 m between perpendiculars |
|
Breadth |
11,42 m |
|
Draught |
Summer: 4,56 m |
|
Air draft |
9,10 m |
|
Freeboard |
1.299 mm |
|
Depth |
5,80 m |
|
Speed |
Max: 10,0 knots |
|
Built |
2010 2021 Lengthened at Kherson - Ukraine with 12,00 m |
|
Launch date |
24/06/2009 |
|
Delivery date |
05/02/2010 |
|
Builder |
189 One Member Limited Liability Company (189 Ship Yard) - Hong Ha Shipyard, HaiPhong - Vietnam |
|
Yard number |
2600-02 |
|
Hull material |
Steel |
|
Continuous decks |
1 |
|
Main engine |
1x ABC 6DZC - 2 stroke single acting 6 cylinder 256 x 310 mm combustion engine 1.104 kW / 1.500 hp at 800 rpm Build: 07/01/2009 Builder: Anglo Belgian Corporation N.V. (ABC), Gent - Belgium |
|
Propellers |
1x Controllable pitch propeller- aft at 335 rpm |
|
Shaft generator |
1x 232 kW / 400 Volt 50 Hz |
|
Generators |
1x Diesel generatorset 121 kW / 400 Volt 50 Hz |
|
Emergency generator |
1x Diesel generatorset 77 kVA - 62 kW - 95 hp |
|
Bow thruster |
1x Tunnel thruster 200 kW / 272 bhp, forward |
|
Number of holds |
2x Box Hold 1: 34,74 x 9,00 x 6,70 m Hold 2: 33,18 x 9,00 x 6,70 m |
|
Cargo hold capacity |
4.093 m³ / 144.137 ft³ |
|
Number of hatches |
1 67,92 x 9,0 m |
|
Hatch type |
Pontoon (11 sections) |
|
Max permitted loads |
Tanktop: 15,0 t/m² On deck: 1,75 t/m² |
|
Tank capacities |
Fuel: 121,79 m³ |
|
Commercial manager |
Rederij Chr. Kornet & Zonen B.V. Beatrix Haven 6-8 4251 NK Werkendam The Netherlands |
|
ISM manager |
Eems Werken BV Beatrixhaven 23 4251 NK Werkendam The Netherlands |
|
Registered owner |
Sea BV, Delfzijl - The Netherlands Care of Rederij Chr Kornet & Zonen BV Beatrix Haven 6-8 4251 NK Werkendam The Netherlands |
|
Previous owners |
02/2010 - 12/2016 Eems Space C.V., Delfzijl- The Netherlands |
|
Latest data adjustment |
30 January 2023 |
