| Westerschelde 25 April 2017 |
 |
|
| Westerschelde 05/04/17 | |
|
Name |
IKAN JEBUH |
|
Type |
General cargo ship - Carriage of dangerous goods |
|
IMO-number |
9478470 |
|
Call sign |
3EWQ |
|
Flag |
Republic of Panama |
|
Port of registry |
Panama City |
|
GT |
21.483 t Suez: 22.044,77 mt |
|
DWT |
33.145 t |
|
NT |
10.828 t Suez: 20.207,33 t |
|
Length |
177,00 m overall 170,00 m between perpendiculars |
|
Breadth |
28,64 m |
|
Draught |
Summer: 10,03 m |
|
Freeboard |
4.392 mm |
|
Depth |
14,35 m |
|
Speed |
Max: 15,7 knots |
|
Built |
2011 |
|
Keel laid |
20/02/2010 |
|
Delivery date |
25/01/2011 |
|
Builder |
Kanda Shipbuilding Co., Ltd. 14-21, 2-Chome Kawajiri-Cho, Higashi, Kure-Shi Hiroshima 737-2607 Japan |
|
Yard number |
515 |
|
Hull material |
Steel |
|
Main engine |
1x Mitsubishi 6UEC45LSE - 2 stroke single acting 6 cylinder 450 x 1.840 mm combustion engine Mcr 6.550 kW / 8.908 bhp at 114,0 rpm Manufacturer: Kobe Diesel Engine Co., Ltd. |
|
Propellers |
1x Fixed pitch propeller |
|
Boilers |
1x Composite auxiliary boiler - 7,8 MPa Manufacturer: Osaka Boiler Mfg. Co.,Ltd. |
|
Generators |
3x Main diesel generatorsets each 440 kW |
|
Number of holds |
5 |
|
Cargo hold capacity |
Bale: 41.207 m³ Grain: 42.630 m³ |
|
Number of hatches |
5 |
|
Tank capacities |
Fuel oil: 1.518,95 m³ Fresh water: 277,92 m³ Ballast: 14.552,22 m³ Lub oil: 91;41 m³ |
|
Cargo gear |
4x Deck cranes - SWL 30,5 t each |
|
Manager |
Daiichi Chuo Marine Co Ltd. Tokyo Japan |
|
Registered owner |
Sea Wealth Navigation SA |
|
Renamed |
2018 Double Diamond Marshall Islands, Majuro - Cal sign: V7HN2 Owner: Good Duke (MI) Ltd. - Hong Kong Manager: Tamar Ship Management Limited - Hong Kong |
|
Latest data adjustment |
05 March 2023 |
