| Westerschelde 13 April 2017 |
|
Name |
CHRISTINE |
|
Previous names |
1998 - 2015 Christina |
|
Type |
General cargo ship - heavycargo - equipped for carriage of containers Multi-purpose vessel for transport of bulk, steel coils, containers, forest products, general cargoes, dangerous cargoes |
|
IMO-number |
9184811 |
|
Call sign |
V2PX5 |
|
Flag |
Antigua & Barbuda |
|
Port of registry |
St. John’s |
|
GT |
2.834 t |
|
DWT |
4.743 t |
|
NT |
1.568 t |
|
Number of 20ft containers |
In hold: 117 On deck: 96 Total: 213 |
|
Container capacity 14t |
In hold: 117 On deck: 96 Total: 157 |
|
Reefer plugs |
20 plugs on deck |
|
Length |
89,90 m overall 84,99 m between perpendiculars |
|
Breadth |
13,17 m |
|
Draught |
6,21 m |
|
Air draft |
Empty: 26,20 m Loaded: 23,40 m |
|
Freeboard |
648 mm |
|
Depth |
7,15 m moulded |
|
Speed |
Max: 11,5 knots |
|
Built |
1998 |
|
Keel laid |
22/01/1998 |
|
Date of completion |
17/12/1998 |
|
Builder casco |
Damen Shipyard Galati Galati Romania Yard number: 928 |
|
Builder completion |
B.V. Scheepswerf Damen Hoogezand The Netherlands Yard number: 730 |
|
Hull material |
Steel |
|
Hull type |
Single hull |
|
Movable bulkheads |
2x Movable, max 3 compartments |
|
Continuous decks |
1 |
|
Main engine |
1x Deutz MWM TBD645L6 - 4 stroke 6 cylinder 330 x 450 mm combustion engine 2.200 kW / 2.989 hp at 600 rpm Builder: Deutz MWM, Mannheim - Germany |
|
Propellers |
1x Controllable pitch propeller |
|
Boilers |
1x CHO Wolf GmbH 65,00 m² - 4,00 bar |
|
Shaft generator |
1x 450 kVA - 360 kW |
|
Generators |
2x Scania 6DS9 main diesel generatorsets each 169 kVA - 135 kW - 182 hp |
|
Emergency / harbour gen. |
1x Valmet diesel generatorset 66 kVA - 53 kW - 72 hp |
|
Compressed air receivers |
2x Starting air compressor |
|
Bow thruster |
1x Fixed pitch thruster 300 kW |
|
Number of holds |
1x Boxshaped 62,49 x 11,00 x 8,43 m narrowing fore and aft |
|
Cargo hold capacity |
Grain/bale: 201.872 ft³ / 5.718 m³ |
|
Hold ventilation |
Electrical driven 6 air-changes per hour |
|
Hatches |
1x Weather deck hatch covers: 10 Steel pontoon hatches with 1 gantry crane 62,70 x 10,10 m |
|
Tank capacities |
Ballast: 1.626,99 m³ IFO: 235,58 m³ MGO: 37,29 m³ Potable water: 41,44 m³ |
|
Other equipment |
3x Separators: 1x IFO, 1x MGO, 1x Lub oil 1x Fuel oil trim pump 1x Bilge water separator, acc. to Marpol regulations 2x Bilge/ballast pumps, each 150 m³/hr a 2,80 bar 1x Fire Fighting pump 1x Sewage pump 1x Freshwater pressure set |
|
ISM & commercial manager |
BF Shipmanagement GmbH & Co KG An der Werft 2 21680 Stade Niederelbe Germany |
|
Registered owner |
Christine Schiffahrt Care of BF Shipmanagement GmbH & Co KG An der Werft 2 21680 Stade Niederelbe Germany |
|
Previous names & owners |
1998 - 2015 Christina - Consailor Conship GmbH & Co Reederei KG ms "Christina" |
|
Renamed |
2022 - 2023 Day Blue Barbados, Bridgetown - Call sign: 8PBO7 Owner: Weships Denizcilik Ve Tic As - Turkey 2023 Day Blue Belize, Belize - Call sign: V3NC9 Owner: Alnilam Shipping Co. |
|
Latest data adjustment |
26 July 2023 |
