| Westerschelde 19 September 2015 |
 |
 |
|
| Westerschelde 10/09/15 | Westerschelde 10/09/15 | |
|
Name |
ANSAC AMITY |
|
Type |
Geared general cargo vessel - Handymax |
|
IMO-number |
9623116 |
|
Call sign |
3FDD9 |
|
Flag |
Republic of Panama |
|
Port of registry |
Panama City |
|
GRT |
20.992 t |
|
DWT |
32.752 t |
|
NRT |
11.228 t |
|
Length |
181,16 m overall |
|
Breadth |
28,40 m moulded |
|
Draught |
Summer: 10,03 m |
|
Moulded L x B x D |
172,50 x 28,40 x 14,25 m |
|
Registered L x B x D |
173,45 x 28,40 x 14,25 m |
|
Freeboard |
Summer: 4.292 mm |
|
Depth |
14,25 m moulded |
|
Speed |
Max: 16,1 knots |
|
Built |
2013 |
|
Keel laid |
29/11/2011 |
|
Launch date |
15/03/2012 |
|
Date of completion |
17/06/2013 |
|
Builder |
Kanda Shipbuilding Co., Ltd. Kawajiri Japan |
|
Yard number |
536 |
|
Hull material |
Steel |
|
Continuous decks |
1 |
|
Main engine
|
1x Mitsubishi/Kobe 6UEC48LSE - 2 stroke single acting 6 cylinder 450 x 1.840 mm combustion engine 6.000 kW at 114,0 rpm Manufacturer: Kobe Diesel Co., Ltd. |
|
Propeller shaft |
1x Oil lubricated shaft without monitoring device Diameter: 455 mm |
|
Propellers |
1 |
|
Boilers |
1x Auxiliary vertical boiler - 0,78 MPa Evaporation: 1,84 t/h Manufacturer: Osaka Boiler Mfg. Co., Ltd. |
|
Generators |
3x Main diesel generatorsets each 311 kW |
|
Number of holds |
5 |
|
Cargo hold capacity |
Bale: 41.964 m³ Grain: 43.488 m³ |
|
Number of hatches |
5 |
|
Tank capacities |
Fuel oil: 1.671 m³ Fresh water: 269 m³ |
|
Cargo gear |
5x Deck cranes each - SWL 30,0 t each |
|
Manager |
Sincere Industrial Corporation, Taipei - Taiwan |
|
Registered owner |
Amity Universal Shipping Corporation |
|
Renamed |
2018 AC Amity Republic of Panama, Panama City - Call sign: 3FDD9 Owner: Amity Universal Shipping Corporation Manager: Sincere Industrial Corporation, Taipei - Taiwan |
|
Latest data adjustment |
13 February 2024 |
