| Westerschelde 24 February 2018 |
|
Name |
THORCO LANNER |
|
Type |
Multi-purpose general cargo fitted with pontoon tween deck, fitted for containers on deck |
|
IMO-number |
9742390 |
|
Call sign |
DUHE |
|
Flag |
Philippines |
|
Port of registry |
Manila |
|
GRT |
13.110 t Suez: 13.707,29 t |
|
DWT |
16.963 t |
|
NRT |
5.042 t |
|
Number of 20ft containers |
160 |
|
Length |
131,66 m overall 122,00 m between perpendiculars |
|
Breadth |
23,00 m moulded |
|
Draught |
Summer: 9,61 m |
|
Moulded L x B x D |
122,00 x 23,00 x 16,00 m |
|
Registered L x B x D |
124,11 x 23,00 x 16,00 m |
|
Keel to mast end |
50,76 m |
|
Air draft |
41,60 m |
|
Freeboard |
Summer: 6.416 mm |
|
Depth |
16,00 m moulded |
|
Speed |
Max: 16,2 knots Service: 14,8 knots |
|
Built |
2015 |
|
Keel laid |
28/06/2014 |
|
Launch date |
20/02/2015 |
|
Date of completion |
19/05/2015 |
|
Builder |
Honda Heavy Industries Saiki Japan |
|
Yard number |
1087 |
|
Hull material |
Steel |
|
Main engine |
1x Hitachi/MAN-B&W 7S35MC-C - 2 stroke single acting 7 cylinder 350 x 1.400 mm combustion engine 5.180 kW at 173,0 rpm Manufacturer: Hitachi Zosen Corporation Innoshima Works - Japan |
|
Propeller shaft |
1x Sea water lubrication shaft Diameter: 360 mm |
|
Propellers |
1x Fixed pitch propeller |
|
Boilers |
1x Auxiliary vertical boiler - 0,70 MPa Evaporation: 1,46 t/h Manufacturer: Miura Co., Ltd. |
|
Generators |
3x Generatorsets total 1.065 kVA |
|
Number of holds |
2 |
|
Cargo hold capacity |
Hold 1: Tank top: 791,10 m² Tweendeck: 978,75 m² Hatchcover: 517,44 m² Total: 2.287,29 m² Hold 2: Tanktop: 766,04 m² Tweendeck: 1.021,50 m² Hatchcover: 655,91 m² Total: 2.443,45 m² Volume (bale/grain): Hold #1: 11.486,7 / 12.145,06 m³ Hold #2: 11.226,35 / 11.964,93 m³ Total: 24.669,66 / 26.066,6 m³ |
|
Number of hatches |
2 |
|
Max. permitted loads |
Tank top: 12,0 t/m² Tweendeck: 4,08 t/m² Hatchcover: 2,50 t/m² |
|
Tank capacities |
HFO 100%: 882,81 m³ MDO 100%: 120,62 m³ Ballast: 5.951,08 m³ Fresh water: 850,19 m³ |
|
Cargo gear |
2x Electro hydraulic cranes (Port Side) - SWL 50,0 t each |
|
Commercial manager |
Thorco Shipping A/S Tuborg Parkvej 10 2900 Hellerup Denmark |
|
ISM manager |
Sea Quest Ship Management Inc 376, Sampaguita Street, San Martin de Porres Ph. 3, Panapaan 4102 Bacoor, Cavite Philippines |
|
Registered owner |
Pisces Carriers Corp SA Care of Thorco Shipping A/S Tuborg Parkvej 10 2900 Hellerup Denmark |
|
Renamed |
2021 Glen Scotia Liberia, Monrovia - Call sign: 5LBX7 Owner: Huiqing Tianjin Shipping Leasing Co., Ltd. - China Manager: Zrich Ship Management Pte. Ltd. |
|
Latest data adjustment |
25 March 2024 |
