Mühlenau - IMO 9313668

Name

MÜHLENAU

Type

Multi-purpose dry cargo ship -Equipped for carriage of containers

Single decker

IMO-number

9313668

Call sign

V2OT1

Flag

Antigua a Barbuda

Port of registry

St. John’s

GT

2.461 t

DWT

3.789 t

DWCC

Summer: 3.550 t

Winter: 3.450 t

NT

1.369 t

Light ship

1.233 t

Number of 20ft containers

176

Length

87,61 m overall

81,00 m between perpendiculars

Breadth

12,90 m extreme

12,80 m moulded

Draught

Summer: 5,59 m

Keel to mast end

24,00 m

Air draft

22,20 m

12,60 m mast lowered

Depth

7,10 m

Speed

Max: 12,3 knots

Service: 11,7 knots

Built

2004

Keel laid

12/06/1998

Launch date

04/08/2004

Date of completion

15/10/2004

Builder

Slovenske Lodenice Komarno a.s. Prevadzkaren

Komarno

Slovakia

Yard number

1955

Hull material

Steel

Bulkheads

2

Continuous decks

1

Main engine

1x MaK 8M20 - 4 stroke 8 cylinder 200 x 300 mm combustion engine 1.520 kW / 2.039 hp at 1.000 rpm

Builder: Caterpillar Motoren GmbH & Co. KG

Propellers

1x Fixed pitch propeller

Generators

3x MAN D 2866 E main diesel generatorsets

Emergency generator

1x Cummins 4BT 3.9-D(M) diesel generatorset

Bow thruster

1x 185 kW

Number of holds

1x Box type

55,75 x 10,20 x 8,15 m

Cargo hold capacity

Bale: 4.585 m³

Grain: 4.612 m³

Number of hatches

1

56,55 x 10,20 m

Hatch cover type

Kvaerner type

Max permitted loads

Tanktop: 15,0 t/m²

Hatch cover: 1,6 t/m²

Tank capacities

Ballast: 1.652,7 m³

Anchor equipment

Length: 440,00 m

Diameter: 36 mm

Manager

Reederei Erwin Strahlmann GmbH Co. KG

Germany

Registered owner

Erwin Strahlmann GmbH & Co. Reederei KG MS " MÜHLENAU "

Germany

Group

R.E.S group

Renamed

12/2020 Wesertal

Portugal, Madeira - Call sign: CQEP4

Registered owner: Schiffahrts UG (haftungsbeschränkt) & Co. KG MS "Wesertal" - Germany

Manager: HS Bereederungs GmbH & Co. KG, Haren Ems - Germany

Latest data adjustment

07 July 2024
