| Westerschelde 10 May 2015 |
 |
|
| Westerschelde 10/05/15 | |
|
Name |
FLORAGRACHT |
|
Type |
General Cargo ship - Heavycargo - Equipped for carriage of containers |
|
IMO-number |
9509968 |
|
Call sign |
PBUS |
|
Flag |
The Netherlands |
|
Port of registry |
Amsterdam |
|
GT |
8.620 t |
|
DWT |
12.200 t excl. tweendeck 11.828 t Incl. tweeneck |
|
NT |
4.398 t |
|
Light ship |
4.919 t |
|
Number of 20ft containers |
658 |
|
Reefer capacity |
120 |
|
Length |
137,07 m overall 128,94 m between perpendiculars |
|
Breadth |
18,90 m moulded |
|
Draught |
8,55 m extreme |
|
Freeboard |
1.136 mm |
|
Depth |
11,65 m moulded |
|
Speed |
Max: 15,7 knots |
|
Built |
2011 |
|
Launch date |
13/04/2011 |
|
Date of completion |
10/08/2011 |
|
Builder |
Jiangsu Yangzi Chanbo Shipbuilding Co. Ltd. Rongcheng China |
|
Yard number |
06-041 |
|
Hull material |
Steel |
|
Hull type |
Single hull |
|
Bulkheads |
Removable pontoons for up to 11 compartments at TEU interval |
|
Continuous decks |
1 |
|
Main engine |
1x Wärtsilä 6R46 - 4 stroke single acting 6 cylinder 460 x 580 mm combustion engine 5.430 kW / 7.378 hp at 500 rpm |
|
Propellers |
1x Controllable pitch propeller - aft at 132 rpm |
|
Boilers |
1 CHR Heatmaster 108,00 m² / 10,0 bar 1 CHO Heatmaster 285,00 m² / 10,0 bar |
|
Generators |
3x Main diesel generatorsets each 413 kVA - 330 kW - 480 hp |
|
Emergency generator |
1x Diesel generatorset 263 kVA - 210 kW - 296 hp |
|
Bow thruster |
1x 500 kW |
|
Number of holds |
2 |
|
Cargo hold capacity |
Bale/Grain: 15.777,91 m³ - 556.980 ft³ |
|
Hold ventilation |
30 Air changes p/h |
|
Hatches |
Weatherdeck: No,1: 26,60 x 15,80 m No,2: 31,74 x 15,80 m No,3: 26,60 x 15,80 m Steel, end folding type Tween deck: No.1: 28,00 x 15,80 m No,2: 61,84 x 15,80 m 17 steel pontoons |
|
Floor space |
Tanktop; 1.280 m² Teendeck: 1.427 m² Weatherdeck: 1.417 m² |
|
Max permitted loads |
Weather deck hatch covers: 2,0 t/m² Tweendeck hatch covers: 4,5 t/m² Tanktop: 20,0 t/m² |
|
Tank capacities |
Fuel: 1.685,7 m³ |
|
Cargo gear |
3x NMT deck cranes - SWL 80,0 t each on starboard side |
|
ISM & commercial manager |
Spliethoff's Bevrachtingskantoor B.V. Radarweg 36 1042 AA Amsterdam The Netherlands |
|
Owner |
Rederij Floragracht Care of Spliethoff's Bevrachtingskantoor BV Radarweg 36 1042 AA Amsterdam The Netherlands |
|
Previous owners |
08/2011- 12/2012 C.V. Scheepvaartonderneming Lootsgracht, Amsterdam - The Netherlands |
|
Latest data adjustment |
14 August 2024 |
