Westerschelde 10 February 2016 |
 |
 |
|
| Westerschelde 10/02/16 | Spijkenisse 13/03/11 | |
|
Name |
ABIS BERGEN |
|
Type |
Multi purpose cargo - Heavy cargo open top - Strengthened for Heavy Cargo - Bottom strengthened for unloading aground - Container cargoes in hold and on the poop deck and on all hatch covers |
|
IMO-number |
9544932 |
|
Call sign |
PBPY |
|
Flag |
The Netherlands |
|
Port of registry |
Harlingen |
|
GT |
2.978 |
|
DWT |
Summer: 3.900 t |
|
NT |
1.384 |
|
Displacement |
5.360 t |
|
Light ship |
1.429 t |
|
Number of 20ft containers |
214 |
|
Length |
89,95 m overall 84,95 m between perpendiculars |
|
Breadth |
14,00 m moulded |
|
Draught |
Max. summer: 5,35 m Max.: winter: 5,24 m |
|
Air draft |
30,74 m |
|
Freeboard |
1.453 mm |
|
Depth |
6,80 m to main deck |
|
Speed |
12,0 knots |
|
Built |
2010 |
|
Keel laid |
15/05/2008 |
|
Date of completion |
08/10/2010 |
|
Builder casco |
Partner Sp.z.o.o. Szczecin Poland Yard number: 104 |
|
Builder completion |
Shipkits B.V. Harlingen The Netherlands Yard number: HDFS-025 |
|
Hull material |
Steel |
|
Movable bulkheads |
Standard equipped with 8 separation bulkheads, can ben used as tweendeck each 4,10 x 10,95 m |
|
Continuous decks |
1 |
|
Main engine |
1x MaK Caterpillar 8M20C - 4 stroke single acting 8 cylinder 255 x 400 mm diesel engine output 1.500 kW / 2.037 bhp |
|
Propeller |
1x Controllable pitch propeller aft at 170 rpm - Right handed Diameter: 3.150 mm - 4 blades |
|
Shaft generator |
1x Stamford 375 kVA |
|
Generators |
2x Caterpillar C9 - 6 cylinder 112 x 149 mm diesel engine each 192 kW at 1.500 rpm coupled with 2 generators each 250 kVA |
|
Bow thruster |
1x 300 kW |
|
Number of holds |
1x Box shaped 56,00 x 11,00 x 8,14 m |
|
Hold capacity |
Grain: 5.049 m³ / 178.300 ft³ |
|
Number of hatches |
1 56,00 x 11,00 m |
|
Max. permitted loads |
Tweendeck: 1,5 t/m Tank top: 15,0 t/m² Hatches + Aft deck: 1,5 t/m² |
|
Tank capacities |
Gas oil: 293,0 m³ Lub oil: 12,0 m³ Ballast: 1.640 m³ / 25 tanks Fresh water: 43,4 m³ Dirty oil: 5,3 m³ Bilge water: 5,4 m³ |
|
Anchor equipment |
2 Weight: 1.440 kg each Length: 220,00 m |
|
Lifting equipment |
1x Gantry crane |
|
Gear |
Gearless |
|
Manager |
Abis Shipping Company B.V. Nieuwe Vissershaven 5 8861 NX Harlingen The Netherlands |
|
Operator |
Peak Project Carriers AS Litleaasveien 49 NO-5132 Nyborg Norway |
|
Owner |
CV MS Bergen II Nieuwe Vissershaven 5 8861 NX Harlingen The Netherlands |
|
Renamed |
10/2017 Peak Bergen The Netherlands, Harlingen - Call sign: PBPY Manager: Peak Project Carriers AS Owner: General Partner Peak Bergen B.V |
|
Latest data adjustment |
04 February 2025 |
