CEG Galaxy - IMO 8222173

Name

CEG GALAXY

Previous names

1983 Wilke

16.09.1988 - Sea Dart
02.05.1989 - Wilke
06.1993 - Scout Marin
05. 08.2008 - CEG Galaxy

Type

General Cargo Ship, equipped for the carriage of containers, single-decker

IMO-number

8222173

Official number

4533

Call sign

V2DT2

Flag

Antigua & Barbuda

Port of registry

St. John's

GT

1.035 t

DWT

1.063 t

NT

326 t

Number of 20ft containers

42

Length

74,54 m overall

71,04 m registered

Breadth

9,51 m overall

9,46 m registered

Draught

Summer: 2,876 m

Air draft

Abt.: 4,80 m

Forecastle

5,00 m

Poop

13,80 m

Freeboard

181 mm

Depth

3,05 m moulded

Speed

10,0 knots

Built

1983

Keel laid

18.06.1982

Launch date

19.05.1983

Date of completion

06.1983

Builder

Julius Diedrich Schiffswerft GmbH & Co. KG
Hafenstr. 20
26802 Moormerland
Federal Republic of Germany

Yard number

148

Hull material

Shipbuilding steel (standard)

Hull type

Double bottom

Watertight bulkheads

4

Continuous decks

2

Main engine

1x Caterpillar 3508 SB - 4 stroke single acting 8 cylinder 170 x 190 mm diesel engine - 746 kW at 1.600 rpm

Year of manufacture: 2000

Manufacturer: Caterpillar
Ketelweg 20
3356 LE Papendrecht
The Netherlands

Propeller

1x Solid propeller - aft at 360 rpm

Electric installations

1x Plant 380/220 V - 170 kVA

1x Plant 380 V - 43 kVA

Generators

2x Main diesel generatorsets each 85 kVA

Harbour generator

1x Diesel generatorset 43 kVA

Compressed air receivers

2x Receivers each 125 litres - 30,0 bar

Bow thruster

1x Transverse thruster JASTRAM - 110 kW, forward

Cargo capacity

Grain:1.883 m³

Bales: 1.866 m³

Hatch

1

Length: 46,82 m

Breadth: 7,45 m

Hold

1

Tank capacities

Fuel oil: 58 m³

Water ballast: 909 m³

Anchor equipment

3x Anchors weight each 780 kg

Chain length: 330,00 m

Crew

6

Manager

Fehn Bereederungs GmbH & Co. KG
Hafenstr. 10a
26789 Leer
Federal Republic of Germany

Operator

Fehn Bereederungs GmbH & Co. KG
Hafenstr. 10a
26789 Leer
Federal Republic of Germany

Owner

MS "CEG GALAXY" GmbH & Co. KG
Grosse Elbstr. 42
22767 Hamburg
Federal Republic of Germany

Registered owner

MS "CEG Galaxy" GmbH & Co. KG
Leer
Federal Republic of Germany

Special annotations

Wheelhouse upper part hydraulic lowering
