Emma - IMO 9374703

Name

EMMA

Type

Multi-purpose dry cargo carrier - Strengthened for heavy cargoes

IMO-number

9374703

Call sign

PHLZ

Flag

The Netherlands

Port of registry

Assen

GT

2.528 t

DWT

3.635 t

NT

1.053 t

Number of 20ft containers

166

Length

89,99 m overall

84,95 m between perpendiculars

Breadth

12,58 m extreme

Draught

5,03 m

Air draft

22,75 m

Depth

8,00 m moulded

Speed

13,0 knots

Built

2007

Keel laid

23/12/2004

Launch date

13/07/2007

Date of completion

07/12/2007

Builder casco

Leda Shipyard (Brodogradiliste Leda D.O.O.)

Korcula

Croatia

Yard number: Y9374703

Builder completion

Peters shipyard B.V.

Kampen

The Netherlands

Yard number: 1014

Hull material

Steel

Continuous decks

1

Main engine

1x Wärtsilä 9L20 - 4 stroke single acting 9 cylinder 200 x 280 mm combustion engine 1.800 kW / 2.448 hp at 1.000 rpm

Manufacturer: Wärtsilä NSD, Zwolle - The Netherlands

Propellers

1x Controllable pitch propeller

Generators

1x Sisu diesel generatorset type 645 DSBIG - 180 kW at 1.500 rpm

1x Sisu diesel generatorset type 420 DSRG - 70 kW at 1.500 rpm

Bow thruster

1x Veth tunnel thruster type VT-200 with E-motor - 250 kW at 1.500 rpm

Number of holds

1

Hold 1: 60,00 x 10,30 x 8,15 m

Number of hatches

1

Hatch 1: 60,00 x 10,30 m

Cargo capacity

4.929 m³ / 174.063 ft³

Commerical manager

Wagenborg Shipping B.V.

Marktstraat 10

9934 CK Delfzijl

The Netherlands

ISM manager

Emma CV

Marktstraat 10

9934 CK Delfzijl

The Netherlands

Owner

Stichting Emma (G. de Vries & H. Bruins)

Marktstraat 10

9934 CK Delfzijl

The Netherlands

Renamed

06/2023 Oderborg

The Netherlands, Delfzijl - call sign: PHLZ

Owner: Wagenborg Shipowners 3 B.V., Delfzijl - The Netherlands

Manager: Wagenborg Shipping B.V., Delfzijl - The Netherlands

Latest data adjustment

13 June 2024
