Westerschelde 02 April 2020 |
 |
 |
|
| Westerschelde 08/10/11 | Antwerpen 24/10/14 |
|
Name |
FEDERAL WELLAND |
|
Type |
Geared bulk carrier - Handymax |
|
IMO-number |
9205926 |
|
Call sign |
V7RG7 |
|
Flag |
Marshall Islands |
|
Port of registry |
Majuro |
|
Previous flag |
2000 - 2016 Hong Kong (Special Administrative Region of China), Hong Kong - Call sign: VRWO9 |
|
GT |
20.659 t |
|
DWT |
Summer: 36.563 t Winter: 35.591 t |
|
NT |
12.019 t Panama: 17.261 t Suez: 18.932 t |
|
Length |
199,99 m overall 191,93 m between perpendiculars |
|
Breadth |
23,76 m extreme |
|
Draft |
Summer:10,75 m Winter: 10,53 m |
|
Depth |
14,85 m |
|
Speed |
14,0 knots |
|
Built |
2000 |
|
Keel laid |
29/06/1999 |
|
Launch date |
30/06/2000 |
|
Date of completion |
14/09/2000 |
|
Builder |
Oshima Shipbuilding Co., Ltd. 1605-1 Oshima-cho 857-2494 Saikai City Japan |
|
Yard number |
10270 |
|
Hull material |
Steel |
|
Transverse bulkheads |
8 |
|
Number of decks |
1 |
|
Main engine |
1x Kawasaki/MAN-B&W 6S46MC-C - 2 stroke 6 cylinder combustion engine 7.981 kW / 10.710 bhp |
|
Propeller |
1x Fixed mono-block propeller Builder: Nakashima Propeller Co., Ltd. |
|
Boilers |
1x Auxiliary boiler, composite GCS-22ST Builder: Aalborg Industries A/S |
|
Generators |
3x Daihatsu 5DK-20 diesel engine generatorsets each 610 kW Builder: Daihatsu Diesel Mfg. Co., Ltd. |
|
Emergency generator |
1x Deutz BF6L913 diesel engine generatorset 125 kW |
|
Bow Thruster |
700 kW |
|
Holds |
6 Hold 1: 26,08 x 8,24 - 19,85 m Hold 2: 26,98 x 19,85 m Hold 3: 25,18 x 19,85 m Hold 4: 21,58 x 19,85 m Hold 5: 26,08 x 19,85 m Hold 6: 26,06 x 19,85 - 9,90 m |
|
Hatches |
6 Hatch 1: 17,10 x 13,20 m Hatch 2: 19,80 x 13,20 m Hatch 3: 19,80 x 13,20 m Hatch 4: 13,50 x 13,20 m Hatch 5: 19,80 x 13,20 m Hatch 6: 18,00 x 13,20 m |
|
Hatch Covers |
Steel folding hydraulic type |
|
Cargo capacity |
Grain / bale: Hold 1: 7.109 / 6.866 m³ Hold 2: 7.990 / 7.663 m³ Hold 3: 7.499 / 7.166 m³ Hold 4: 6.394 / 6.089 m³ Hold 5: 7.759 / 7.412 m³ Hold 6: 7.333 / 7.093 m³ Total: 44.084 m³ / 42.289 m³ |
|
Tank capacities |
Ballast: 19.731 m³ Fuel IFO: 1.445 m³ MGO: 447 m³ |
|
Gear |
3x Electro - hydraulic deck crane - SWL 30,0 t each |
|
Crew size |
30 |
|
Manager |
Anglo-Eastern Ship Management Ltd. 23/F, 248 Queen`s Road East, Wanchai Hong Kong |
|
Operator |
Fednav Group 1000 de La Gauchetière Street West Suite 3500 Montreal, QC H3B 4W5 Canada |
|
Registered owner |
Federal Oceans Ltd. Hong Kong |
|
Previous owners |
2000 - 2000 Fednav Ltd. 1000 de La Gauchetière St., West, Suite 3500 H3B 4W5 Montreal Canada |
|
Latest data adjustment |
11 July 2020 |
