Westerschelde 19 October 2015 |
 |
 |
 |
 |
|||
| Antwerpen 19/03/09 | Westerschelde 09/11/11 | Vlissingen 02/06/17 | Westerschelde 12/01/19 |
|
Name |
HELENIC |
|
Type |
Multi-purpose dry cargo carrier - Strengthened for heavy cargoes - Container ship |
|
IMO-number |
9356490 |
|
Call sign |
PHNX |
|
Flag |
The Netherlands |
|
Port of registry |
Andijk |
|
GT |
2.281 t |
|
DWT |
Summer: 3.150 t |
|
DWCC |
3.442 t |
|
NT |
1.229 t |
|
Container capacity 20 ft |
104 |
|
Length |
88,97 m overall 84,99 m between perpendiculars |
|
Breadth |
12,40 m overall 11,80 m moulded |
|
Draught |
Summer: 5,05 m |
|
Air draft |
15,47 m in ballast |
|
Keel to mast end |
24,50 m |
|
Freeboard |
1.852 mm |
|
Depth |
6,90 m |
|
Speed |
13,0 knots |
|
Built |
2008 |
|
Build start |
01/01/2007 |
|
Launch date |
28/04/2007 |
|
Date of completion |
09/03/2008 |
|
Builder casco |
Odenice Nova Melnik s.r.o Melnik Czech Republic |
|
Builder completed |
Bijlsma Shipyard B.V. (Veka) Lemmer The Netherlands |
|
Yard number |
751 |
|
Hull material |
Steel |
|
Watertight compartments |
5 |
|
Moveable bulkheads |
2 |
|
Continuous decks |
1 |
|
Main engine |
1x Wärtsilä 8L20 - 4 stroke single acting 8 cylinder 200 x 280 mm combustion engine Mcr 1.499 kW / 2.038 hp at 1.000 rpm Built: 01/2006 Builder: Wärtsilä Diesel Oy, Turku - Finland |
|
Electrical propulsion generator |
1x 390 kW - 400 V |
|
Number of screws |
1x Screw propeller controllable pitch |
|
Shaft generator |
390 kW |
|
Generators |
1x Diesel generatorset 175 kVA - 140 kW - 204 hp |
|
Emergency genertor |
1x Diesel generatorset 52 kVA - 42 kW - 72 hp |
|
Bow thruster |
1x Tunnel thruster 360 kW / 489 bhp, forward |
|
Number of holds |
1x Fully box, double skinned 63,00 x 9,60 x 7,50 m |
|
Cargo hold capacity |
Grain / bale: 158.985 ft³ / 4.501 m³ |
|
Timber capacity |
3.760 m³ |
|
Cargo hold ventilation |
Electrical ventilation 9 air changes per hour basis empty hold Hold is fitted with dehumidifier system |
|
Number of hatches |
1 63,00 x 9,60 m |
|
Hatch cover type |
Coops & Nieborg pontoon hatches |
|
Max permitted loads |
Tanktop: 12,0 t/m² Hatch covers: 1,60 t/m² |
|
Tank capacities |
HFO: 225,5 m³ MGO: 35,0 m³ Water ballast: 1.282,2 m³ Fresh water: 44,0 m³ |
|
Cargo gear |
Gearless |
|
Crew size |
6 |
|
Commerical manager |
Wagenborg Shipping Marktstraat 10 9934 CK Delfzijl The Netherlands |
|
ISM manager |
Triton Scheepvaart CV Marktstraat 10 9934 CK Delfzijl The Netherlands |
|
Reg Owner |
A.H.T. Hagebeuk, Andijk - The Netherlands Care of Wagenborg Shipping BV Marktstraat 10 9934 CK Delfzijl The Netherlands |
|
Latest data adjustment |
07 February 2022 |
