| Antwerpen 10 May 2009 |
|
Name |
HENDRIK-S |
|
Previous name |
2001 - 24.06.2005 Aquatique |
|
Type |
General cargo ship - Strengthened for heavy cargo, equipped for carriage of containers |
|
IMO-number |
9195391 |
|
Call sign |
PFCP |
|
Flag |
The Netherlands |
|
Previous flag |
29.04.2001 - Cyprus |
|
Port of registry |
Kampen |
|
GT |
2.301 t |
|
DWT |
Summer: 3.171 t |
|
NT |
1.289 t |
|
Number of 20ft containers |
132 |
|
Length |
82,51 m overall 79,25 m registered |
|
Breadth |
12,40 m overall |
|
Draught |
Summer: 5,30 m |
|
Forecastle |
8,85 m |
|
Freeboard |
1.409 mm |
|
Depth |
6,70 m moulded |
|
Speed |
11,5 knots |
|
Built |
2001 |
|
Keel laid |
29.06.1998 |
|
Launch date |
09.09.2000 |
|
First movement |
12.02.2001 |
|
Date of completion |
03.2001 |
|
Builder casco |
Daewoo Mangalia Heavy Industries S.A. Yard number: 1020 |
|
Builder completed |
Pattje Saimax Yard number: 420 |
|
Hull material |
Shipbuilding steel (higher tensile) |
|
Hull type |
Double hull Double bottom |
|
Watertight bulkheads |
4 |
|
Continuous decks |
1 |
|
Main engine |
1x MaK 6 M 25 - 5 stroke single acting 6 cylinder 255 x 400 mm diesel engine - 1.800 kW Year of manufacture: 2000 Manufacturer: Caterpillar Motoren GmbH & Co. KG |
|
Number of screws |
1x Controllable pitch propeller - aft |
|
Boiler |
Water heater, oil fired - 5,0 bar |
|
Electric installations |
1x 380/220 V - 226 kVA 1x 380 V - 300 kVA 1x 380 V - 113 kVA |
|
Shaft generator |
1x 300 kVA |
|
Generators |
2x Main diesel generatorsets each 113 kVA |
|
Emergency generator |
1x Dieel generatorset 113 kVA |
|
Compressed air receivers |
2x Receivers 250 litres - 30,0 bar |
|
Bow thruster |
1x Transverse thruster JASTRAM - 200 kW, forward |
|
Cargo capacity |
Bales: 4.782 m³ Grain: 4.782 m³ |
|
Tank capacities |
Ballast: 1.394 m³ Fuel oil: 217 m³ |
|
Anchor equipment |
3x Anchors weight each 1.740 kg |
|
Crew size |
5 |
|
Manager |
Rederij H. Steenstra B.V. |
|
Owner |
B.V. Motorschip "HENDRIK-S" |
