Malachit - IMO 8801632

Name

MALACHIT

Previous names

1989 - 11.1989 Steelca

1989 - 06.1993 Aleksandr Ovchinnikov

1993 - 02.2003 Aleksandrov

2003 - 08.2004 Tasman Chief

2004 - 08.2007 Aleksandro - Flag: Russian Federation

Type

General dry cargo ship - Double decker vessel

convertible to single decker

IMO-number

8801632

Call sign

P3QX3

Flag

Cyprus

Port of registry

Limassol

GT

6.030 t

DWT

9.683 t

NT

3.602 t

Lightweight

3.670,8 t

Number of 20ft containers

564

Reefer capacity

50

Length

113,12 m overall

106,00 m between perpendiculars

Breadth

19,22 m extreme

18,90 m moulded

Draught

8,54 m

Air draft

37,2 m

Freeboard

Summer: 2.787 mm

Winter: 2.965 mm

Depth

11,28 m moulded

Speed

12,5 knots

Built

1989

Launch date

24.08.1988

Date of completion

04.08.1989

Builder

Miho Zosensho Shipyard
Shizuoka
Japan

Yard number

1334

Hull material

Steel

Bulkheads

Transverse: 3

Main engine

1x Han Shin 6LF58 - 6.000 hp

Propellers

1x Kamewa controllable pitch propeller

Boilers

1x Thermal oil heater, exhaust heated WAQ5-48

1x Thermal oil heater, oil fired SH6

Generators

3x Mitsubishi S6N-MPTA main generatorsets

Number of holds

Lower deck:

73,50 x 15,70 x 4,41 m

Tween deck:

74,20 x 18,40 x 6,00 m

Cargo capacity

Grain: 11.590,57 m³

Bales: 11.527,75 m³

Hatchway dimensions

Weather deck

Hatch 1: 33,60 x 15,70 m

Hatch 2: 35,70 x 15,70 m

Tween deck:

70,70 x 15,70 m

Hatch covers (weather deck)

Macgregor end folding type each cover of 4 flat steel panels, hydraulic

Hatch covers (tweendeck)

Total 11 sections:

Flush type side opening with crane except first section opening fwd by hydraulic

Area

Lower hold: 1001,60 m³

Tween deck: 1.365,20 m²

Total: 2.366,80 m²

Max. permitted loads

Hatch covers (Weather deck): 1,75 t/m²

Twin deck covers: 3,70 t/m²

Tank top: 20,0 t/m²

Ballast capacity

2.200,9 m³

Hold ventilation

25 Air changes per hour

Cargo gear

2x Cranes
SWL 50 t @ 18,00 m

SWL 40 t @ 24,00 m

Manager

Unicom Management Services (Cyprus) Ltd.
Unicom Tower, Maximos Plaza
Maximos Michaelides Street
3106 Neapolis, Limassol
Cyprus

Operator

EuroAfrica Shipping Lines
Limassol
Cyprus

Registered owner

POL-FIN Shipping Company Limited
229, Arch. Makarios III Ave Meliza Court
3105 Limassol
Cyprus

Previous owners

1989 - 2007 Aleksandr Ovchinnikov Shipping Co. Ltd.

Last update

28.04.2013
