| Westerschelde 10 March 2016 |
 |
 |
 |
||
| Westerschelde 30/11/11 | Antwerpen 07/08/17 | Westerschelde 02/06/20 | ||
|
Name |
MILA |
|
Previous names |
2006 - 20/12/2007 Iselmar |
|
Type |
Multi-purpose dry cargo carrier - Strengthened for heavy cargoes |
|
IMO-number |
9331335 |
|
Call sign |
PHGM |
|
Flag |
The Netherlands |
|
Port of registry |
Alkmaar |
|
Previous flag |
2006 - 2007 The Netherlands, Delfzijl - Call sign: PHGM |
|
GT |
2.528 t |
|
DWT |
3.636 t |
|
DWCC |
Summer: 3.350 t |
|
NT |
1.053 t |
|
Number of 20ft containers |
157 |
|
Length |
89,99 m overall 84,95 m between perpendiculars |
|
Breadth |
12,50 m moulded 15,58 m extreme |
|
Draught |
Summer: 5,30 m Winter: 5,20 m |
|
Air draft |
22,75 m in ballast |
|
Depth |
8,00 m moulded |
|
Speed |
13,5 knots |
|
Built |
2006 |
|
Keel laid |
01/12/2004 |
|
Launch date |
11/03/2006 |
|
Delivery date |
25/08/2006 |
|
Builder casco |
Leda Shipyard D.O.O. Korcula Croatia Yard number: Y9331335 |
|
Builder completion |
Scheepswerf Peters B.V. Kampen The Netherlands Yard number: 1205 |
|
Hull material |
Steel |
|
Hull type |
Double skinned |
|
Number of decks |
1 |
|
Main engine |
1x Wärtsilä 9L20 - 4 stroke single acting 9 cylinder combustion engine 1.800 kW / 2.448 hp at 1.000 rpm Manufacturer: Wärtsilä Diesel Oy, Turku - Finland |
|
Propeller |
1x Controllable pitch propeller |
|
Generators |
1x Sisu Diesel 645 DSBIG diesel generatorset 180 kW at 1.500 rpm 1x Sisu Diesel 420 DSBIG diesel generatorset 70 kW at 1.500 rpm |
|
Bow thruster |
1x Veth Tunnel Thruster VT-200 with E-motor 250 kW at 1.500 rpm |
|
Number of holds |
1x Fully box 60,00 x 10,30 x 8,15 m |
|
Cargo hold capacity |
Grain/bale: 174.063 m³ / 4.927 m³ |
|
Hold ventilation |
6x Air changes per hour basis empty hold Hold is fitted with dehumidifier system |
|
Hatch |
1 60,00 x 10,30 |
|
Hatch type |
Pontoon |
|
Tank capacities |
MGO: 250 m³ Water ballast: 1.466 m³ Fresh water: 25 m³ |
|
Commercial manager |
Wagenborg Shipping Marktstraat 10 9934 CK Delfzijl The Netherlands |
|
ISM manager |
Sital Scheepvaartonderneming Dorpsstraat 84 1731 RJ Winkel The Netherlands |
|
Owner |
Aniel K.S. Sital Dorpsstraat 84 Winkel 1731 RJ The Netherlands |
|
Previous names & owners |
09/2006 - 12/2007 Iselmar - Roel en Anet Oldekamp, Lemmer - The Netherlands |
|
Latest data adjustment |
23 February 2023 |
