| Westerschelde 19 January 2012 |
 |
| Westerschelde 19/01/12 |
|
Name |
MUNTEBORG |
|
Previous names |
1997 Munteborg 2000 MSC Baltic |
|
Type |
Multi-purpose dry cargo ship - heavy cargo - Container ship |
|
IMO-number |
9179385 |
|
Call sign |
PHAX |
|
Flag |
The Netherlands |
|
Port of registry |
Delfzijl |
|
GT |
6.540 t |
|
DWT |
9.141 t |
|
NT |
3.464 t |
|
Number of 20ft containers |
604 |
|
Length |
134,55 overall 127,20 m between perpendiculars |
|
Breadth |
16,53 m |
|
Draught |
7,10 m |
|
Air Draft |
33,50 m |
|
Depth |
9,80 m |
|
Speed |
15,5 knots |
|
Built |
1998 |
|
Date of completion |
15.10.1998 |
|
Builder |
Bijlsma Shipyard BV |
|
Yard number |
682 |
|
Hull material |
Steel |
|
Watertight compartments |
8 |
|
Continuous decks |
2 |
|
Main engine |
1x Stork Wärtsilä 8L38 - 4 stroke 8 cylinder 380 x 475 mm diesel engine - 5.280 kW / 7.173 hp at 600 rpm Built: 1998 Builder: Wärtsilä, Zwolle - The Netherlands |
|
Propelling system |
1x Screw propeller controllable pitch at 145 rpm |
|
Boilers |
1x CHM Weisloch Marine 22,20 m² - 10,0 bar |
|
Electrical installation |
Power voltage: 380 V Lighting voltage: 220 V Frequency: 60 Hz |
|
Shaft generators |
1x 938 kVA - 750 kW |
|
Generators |
3x Diesel generatorsets each 337 kVA - 269 kW |
|
Number of holds |
2 Dimension: Hold 1: 39,20 x 13,50 x 10,86 m Hold 2: 52,50 x 13,50 x 10,86 m |
|
Total capacity of holds |
13.086 m³ |
|
Cargo hatchways |
2 Dimension: Hatch 1: 39,20 x 10,50 m Hatch 2: 52,50 x 13,50 m |
|
Fuel capacity |
680 m³ |
|
Manager |
Wagenborg Shipping |
|
Operator |
Wagenborg Shipping B.V. |
|
Owner |
Wagenborg Shipping |
|
Registered owner |
C.V.S.O. Munteborg Scheepvaartonderneming C.V. |
|
Renamed |
06.07.2012 Simushir |
