| Westerschelde 23 November 2011 |
|
Name |
PLANET V |
|
Previous names |
1994 - 25.09.1996 Planet 5 |
|
Type |
General cargo ship - Equipped for carriage of containers - With removable stowage appliances |
|
IMO-number |
9087532 |
|
Call sign |
V2FS3 |
|
Flag |
Antigua & Barbuda |
|
Port of registry |
St. John's |
|
GT |
4.984 t |
|
DWT |
7.000 t |
|
NT |
2.103 t |
|
Number of 20ft containers |
549 |
|
Number of 40ft containers |
255 |
|
Container capacity 14t |
330 |
|
Reefer capacity |
80 |
|
Length |
116,20 m overall 107,96 m registered |
|
Breadth |
19,20 m registered |
|
Draught |
7,050 m |
|
Forecastle |
8,54 m |
|
Poop |
14,00 m |
|
Freeboard |
2.162 mm |
|
Depth |
9,20 m moulded |
|
Speed |
16,5 knots |
|
Built |
1994 |
|
Keel laid |
25.05.1993 |
|
Launch date |
09.04.1994 |
|
Date of completion |
05.1994 |
|
Builder |
Schiffswerft Hugo Peters Wewelsfleth Peters & Co. GmbH |
|
Yard number |
645 |
|
Hull material |
Shipbuilding steel (standard) |
|
Hull type |
Partly double bottom |
|
Watertight bulkheads |
5 |
|
Continuous decks |
2 |
|
Main engine |
1x Man 9 L 32/40 - 4 stroke 9 cylinder 320 x 400 mm diesel engine - 3.960 kW at 750 rpm Reduced power: 2.100 kW Year of manufacture: 1994 Manufacturer: MAN B&W Diesel GmbH |
|
Propellers |
1x Controllable pitch propeller - aft at 135 rpm |
|
Electric installations |
1x Plant 400/220 V - 287,5 kVA 1x Plant 400 V - 760 kVA 1x Plant 400 V - 94 kVA |
|
Shaft generator |
1x 608 kW / 760 kVA |
|
Generators |
1x Main diesel generatorsets each 230 kW / 287,5 kVA |
|
Emergency generator |
1x Diesel generatorset 94 kVA |
|
Compressed air receivers |
2x Receivers each 500 litres - 30,0 bar 1x Receiver 30 litres - 30,0 bar |
|
Bow thruster |
1x Transverse thruster JASTRAM - 353 kW, forward |
|
Cargo capacity |
Grain:7.150 m³ Bales: 7.000 m³ |
|
Anchor Equipment |
3x Anchors weight each 3.780 kg Chain length: 522,50 m |
|
Cargo gear |
Gearless |
|
Manager |
Peter Döhle Schiffahrts-KG |
|
Owner |
Gerdau Reederei |
|
Registered owner |
Reedereigesellschaft MS "PLANET" Henry Gerdau KG (GmbH & Co.) |
