| Westerschelde 24 April 2017 |
 |
 |
 |
 |
 |
 |
|||||
| Westerschelde 27/01/15 | Westerschelde 27/01/15 | Westerschelde 16/11/12 | Antwerpen 12/12/19 | Westerschelde 26/07/19 | Westerschelde 14/10/19 | |||||
|
Name |
EKEN |
|
Type |
General cargo ship - Single-decker, box-shaped |
|
IMO-number |
9263564 |
|
Call sign |
OZ2129 |
|
Flag |
Faeroe Islands |
|
Port of registry |
Tórshavn |
|
Previous flags |
03/2003 - 04/2004 The Netherlands, Delfzijl - Call sign: PJBM 04/2004 - 06/2012 Sweden, Lidköping - Call sign: SBJI |
|
GT |
2.556 t |
|
DWT |
Summer: 4.775 t |
|
NT |
1.406 t |
|
Length |
89,00 m overall 84,99 m between perpendiculars |
|
Breadth |
13,35 m extreme |
|
Draught |
Max.: 5,85 m |
|
Freeboard |
1.655 mm |
|
Depth |
7,50 m |
|
Speed |
12,5 knots |
|
Built |
2003 |
|
Launch date |
08/02/2003 |
|
Date of completion |
14/03/2003 |
|
Builder |
Ferus Smit Leer GmbH Leer Germany |
|
Yard number |
337 |
|
Hull material |
Steel |
|
Watertight compartments |
5 |
|
Continuous decks |
1 |
|
Main engine |
1x Wärtsilä 6L26 - 4 stroke 6 cylinder 260 x 320 mm combustion engine 1.860 kW / 2.527 hp at 900 rpm Built: 2002 Builder: Wärtsilä Italia Spa, Trieste - Italy |
|
Propellers |
1x Screw propeller controllable pitch - aft at 216 rpm |
|
Electric installations |
Power Voltage: 400 V Lighting Voltage: 220 V Frequency: 60 Hz |
|
Shaft generator |
1x 406 kVA - 325 kW |
|
Generators |
1x Diesel generatorset 97 kVA - 78 kW - 116 hp 1x Diesel generatorset 219 kVA - 175 kW - 318 hp |
|
Bow thruster |
1x 270 kW |
|
Number of holds |
2 Hold 1: 22,10 x 11,60 / 7,80 x 7,50 m Hold 2: 39,25 x 11,60 x 7,50 m |
|
Total hold capacity |
Hold 1: 1.748 m³ / 61.767 ft³ Hold 2: 3.372 m³ / 119.152 ft³ Total: 5.120 m³ / 180.919 ft³ |
|
Number of hatches |
2 Hatch 1: 19,50 x 10,40 m Hatch 2: 39,00 x 10,40 m |
|
Manager |
Thun Ship Management Holland Farmsum The Netherlands |
|
Previous managers |
03/2003 - 06/2007 Marin Ship Management B.V., Farmsum - The Netherlands |
|
Owner |
C.V. Scheepvaartonderneming Eken Delfzijl The Netherlands |
|
Registered owner |
Erik Thun AB SE-531 32 Östra Hamnen 7 Lidköping Sweden |
|
Latest data adjustment |
04 November 2021 |
