| Westerschelde 20 November 2012 |
 |
 |
|
| Antwerpen 14/12/15 | Vlissingen 18/04/18 | |
|
Name |
WILSON HERON |
|
Previous names |
1994 built as: Ilka 08/1994 - 01/2008 Garmo |
|
Type |
General cargo ship - Strengthened for heavy cargo |
|
IMO-number |
9116022 |
|
Call sign |
8PBB8 |
|
Flag |
Barbados |
|
Port of registry |
Bridgetown |
|
Previous flags |
1994 - 1994 Germany 1994 - 2008 Cyprus 2008 - 2021 Malta, Valletta - Call sign: 9HJW9 |
|
GT |
2.901 t |
|
DWT |
Summer: 4.228 t Winter: 4.095 t |
|
NT |
1.693 t |
|
Number of 20ft containers |
241 |
|
Length |
91,12 m overall 84,92 m registered |
|
Breadth |
13,80 m registered |
|
Draught |
5,75 m |
|
Keel to mast end |
36,50 m |
|
Air draft |
33,00 m |
|
Forecastle |
6,02 m |
|
Poop |
12,60 m |
|
Depth |
7,15 m moulded |
|
Speed |
12,5 knots |
|
Built |
1994 |
|
Keel laid |
15/04/1994 |
|
Launch date |
22/10/1994 |
|
Date of completion |
25/11/1994 |
|
Builder |
Scheepswerf J. Pattje B.V. Waterhuizen 7 9609 PA Hoogezand The Netherlands |
|
Yard number |
387 |
|
Hull material |
Shipbuilding steel (standard) |
|
Hull type |
Single hull Partly double bottom (e.g. interrupted in way of machinery space) |
|
Watertight bulkheads |
4 |
|
Movable bulkhead |
1x Movable bulkhead in three parts, each part 2,80 m high, total height 8,40 m - three different positions |
|
Continuous decks |
1 |
|
Main engine |
1x MaK 6M453C - 4 stroke 6 cylinder 320 x 420 mm combustion engine 2.200 kW / 2.991 hp at 600 rpm Year of manufacture: 1994 Manufacturer: Krupp Mak Maschinenbau GmbH Falckensteiner Str. 2 24159 Kiel Federal Republic of Germany |
|
Propellers |
1x Controllable pitch propeller - aft at 183 rpm |
|
Electric installations |
1x Plant 380/220 V - 181 kVA 1x Plant 380 V - 270 kVA 1x Plant 380 V - 100 kVA |
|
Shaft generator |
1x 270 kVA |
|
Generators |
1x Caterpillar 3306 DIT main diesel generatorset 181 kVA |
|
Emergency generator |
1x Diesel generatorset 100 kVA |
|
Compressed air receivers |
2x Receivers each 250 litres - 30,0 bar 1x Receiver 30 litres - 30,0 bar |
|
Bow thruster |
1x Transverse thruster JASTRAM - 200 kW, forward |
|
Number of holds |
1 Dimensions: 62,65 x 11,20 x 8,45 m |
|
Number of hatches |
1 Dimensions: 62,63 x 11,20 m |
|
Hatch type |
Pontoon type |
|
Cargo capacity |
Grain & Bales: 5.620 m³ - 198.476 ft³ |
|
Tank capacities |
Fuel: 234 m³ Diesel oil: 70 m³ Ballast water: 1.625,2 m³ |
|
Anchor equipment |
3x Anchors weight each 1.920 kg Chain length: 440,00 m Diameter: 38 mm |
|
Commercial manager |
Wilson Eurocarriers AS Bradbenken 1 5003 Bergen Norway |
|
ISM manager |
Wilson Ship Management AS Bradbenken 1 5003 Bergen Norway |
|
Previous managers |
1994 - 2004 Atlas Trampship Reederei GmbH & Co. MS "ILKA" KG 2004 - 2008 Reederei Hesse GmbH & Co. KG |
|
Operator |
Wilson |
|
Registered owner |
Wilson Shipowning AS Care of Wilson EuroCarriers AS Bradbenken 1 5003 Bergen Norway |
|
Previous owners |
1994 - 1994 Reederei Alfred Hartmann KG 1994 - 2004 Bell Raider Shipping Co. Ltd 2004 - 2008 ATL Reederei GmbH & Co. MS "GARMO" KG |
|
Latest data adjustment |
18 November 2022 |
