| Westerschelde 05 January 2020 |
 |
 |
|
| Westerschelde 06/06/12 | Westerschelde 06/06/12 | |
|
Name |
NOEST |
|
Previous names |
10/1995 - 12/2001 Laurina Neeltje 12/2001 - 03/2005 Laurina 03/2005 - 05/2006 Stina |
|
Type |
General cargo ship - Box shaped |
|
IMO-number |
9120102 |
|
Call sign |
PHFN |
|
Flag |
The Netherlands |
|
Port of registry |
Roden |
|
Previous flags |
10/1995 - 03/2005 The Netherlands, Werkendam - Call sign: PFND 03/2005 - 07/2005 ? 07/2005 - 05/2006 Antigua & Barbuda, St. John’s |
|
GT |
1.546 t |
|
DWT |
Summer: 2.335 t |
|
DWCC |
Summer: 2.240 t Winter: 2.170 t |
|
NT |
867 t |
|
Number of 20ft containers |
77 |
|
Length |
84,95 m overall 80,78 m between perpendiculars 80,95 m registered |
|
Breadth |
10,80 m extreme 10,70 m registered |
|
Draught |
Summer: 4,14 m Winter: 4,01 m |
|
Keel to mast end |
19,00 m |
|
Air draft |
9,00 m in ballast |
|
Forecastle |
7,15 m |
|
Quarterdeck |
13,20 m |
|
Depth |
5,35 t |
|
Speed |
9,5 knots loaded 10,5 knots in ballast |
|
Built |
1995 |
|
Keel laid |
01/02/1995 |
|
Launch date |
22/08/1995 |
|
Delivery date |
28/10/1995 |
|
Builder |
Peters Scheepsbouw B.V. Haatlanderdijk 1 8265 AN Kampen The Netherlands |
|
Yard number |
443 |
|
Hull material |
Shipbuilding steel (standard) |
|
Hull type |
Partly double bottom (e.g. interrupted in way of machinery space) |
|
Watertight bulkheads |
4 |
|
Grain bulkhead |
1x Moveable bulkhead for 5 positions |
|
Continuous decks |
1 |
|
Main engine |
1x ABC 6MDZC-800-173 - 4 stroke single acting 6 cylinder 256 x 310 mm combustion engine 999 kW / 1.020 bhp at 700 rpm Reduced to: 749 kW Year of Manufacture: 1995 Manufacturer: Anglo Belgian Corporation N.V. Wiedauwkaai 43 9000 Gent Belgium |
|
Propellers |
1x Fixed pitch propeller - aft at 272 rpm |
|
Electric installations |
2x Plants each 380 V - 80 kVA 1x Plant 380 V - 50 kVA |
|
Generators |
2x Main diesel generatorsets each 80 kVA |
|
Emergency + Harbour gen. |
1x Diesel generatorset 50 kVA |
|
Compressed air receivers |
2x Receivers each 1.200 litres- 35,0 bar |
|
Bow thruster |
1x VETH jet 243 kW, forward |
|
Number of holds |
1 60,60 x 8,68 x 5,82 m |
|
Hold capacity |
Grain: 3.056 m³ Bales: 3.050 m³ |
|
Number of hatches |
1 60,60 x 8,68 m |
|
Type of hatch |
Pontoon covers (9 pieces) |
|
Strength |
Tanktop: 8,0 t/m² Hatchcover: 1,56 t/m² |
|
Tank capacities |
Bunker MGO: 128 m³ Freshwater: 21 m³ Ballast water: 1.122 m³ |
|
Anchor equipment |
3x Anchors weight each 1.140 kg Chain Length: 385,00 m |
|
Cargo gear |
None |
|
Crew size |
9 |
|
ISM & commercial manager |
Boomsma Shipping B.V. Harste 15 8602 JX Sneek The Netherlands |
|
Previous manager |
|
|
Registered owner |
Noest Shipping B.V. Oldengaerde 40 9301 WT Roden The Netherlands |
|
Previous names & owners |
|
|
Renamed |
03/12/2021 Paulin-B Germany, Elsfleth - Call sign DGDZ2 Manager: JEB Bereederungs G.m.b.H. & Co. K.G., Elsfleth - Germany Owner: Lily-B Schifffahrts G.m.b.H. & Co. K.G., Elsfleth - Germany |
|
Latest data adjustment |
06 May 2023 |
