Diamonde - IMO 8501062

Name

DIAMONDE

Previous names

1985 - 03/1999 Diamond

Type

General cargo ship - Strengthened for heavy cargo

Single decker - Boxline

IMO-number

8501062

Call sign

5VES6

Flag

Togo

Port of registry

Lomé

Previous flags

• 07/1985 The Netherlands, Rotterdam - Call sign: PDQC

• 05/1995 Netherlands Antilles,Willemstad - call sign: PJSW

• 01/1997 The Netherlands, Rotterdam - Call sign: PCAF

• 03/1999 The Netherlands, Ridderkerk - Call sign: PDQZ

• 05/1999 The Netherlands, Rotterdam - Call sign: PDQZ

• 09/2003 - 01/2017 St. Vincent & Grenadines, Kingstown - Call sign: J8B2878

GT

1.487

DWT

2.475 t

DWCC

Summer: 2.350 t

Winter: 2.300 t

NT

833

Length

79,62 m overall

75,11 m registered

Breadth

11,33 m registered

Draught

4,43 m

Air draft

6,50 m

Forecastle

5,42 m

Poop

13,38 m

Depth

5,62 moulded

Speed

10,0 knots

Built

1985

Keel laid

26/10/1984

Launch date

31/05/1985

Delivery date

01/07/1985

Builder

Machinefabriek Vervako Heusden B.V.

Bakkersdamm 5-7

5256 PK Heusden

The Netherlands

Yard number

2911

Hull material

Shipbuilding steel (higher tensile)

Hull type

Double bottom, continuous from peak to peak bulkhead

Watertight bulkheads

4

Continuous decks

1

Main engine

1x Stork-Werkspoor 6SW240 - 4 stroke single acting 6 cylinder 240 x 260 mm combustion engine 897 kW / 1.220 bhp at 1.000 rpm

Year of manufacture: 1984

Manufacturer: Stork-Werkspoor Diesel B.V.

Assendorperlure 5

Zwolle

The Netherlands

Propellers

1x Solid propeller, aft at 333 rpm

Boilers

Water heater, oil fired - 4,0 bar

Year of Manufacture: 1985

Electric installations

2x Plants each 380/220 V - 94 kVA

1x Plant 380 V - 40 kVA

Generators

2x Main diesel generatorsets each 94 kVA

Harbour generator

1x Diesel generatorset 401 kVA

Compressed air receivers

2x Receivers each 125 litres - 30,0 bar

Bow thruster

1x Bow thruster Snijder Hasselt - 180 kW, forward

Number of holds

1

55,47 x 9,20 m

Cargo capacity

Grain: 6.046 m³

Bales: 3.052 m³

Number of hatches

1

45,81 x 8,90 m

Max permitted loads

Tanktop: 10,0 t/m²

Anchor equipment

3x Anchors weight each 1.290 kg

Chain length: 385,00 m

Crew size

10

Manager

Navilat Sia

Liepaja (Libau)

Latvia

Previous manager

• 07/1985 Sanara, Kustvaart-, Bevrachtings- en Overslagbedrijf B.V. (later Sanara (KBO) B.V., Rotterdam - The Netherlands

• 05/1995 Sea River Chartering Holding B.V., Rotterdam - The Netherlands

• 03/1999 Q Trend B.V., Rotterdam - The Netherlands

• 05/1999 Q Shipping B.V., Ridderkerk - The Netherlands

• 09/2003 - 01/2017 Navilat Sia, Liepaja (Libau) - Latvia

Owner

Baltic Shipping Ltd.

Liepaja (Libau)

Latvia

Previous names & owners

• 07/1985 Diamond - Diamond Shipping B.V., Rotterdam - The Netherlands

• 05/1995 Diamond - Diamond Pride Shipping N.V., Willemstad (NA) - Netherlands Antilles

• 01/1997 Diamond - Diamond Shipping B.V., Rotterdam - The Netherlands

• 03/1999 Diamonde - Diamond C.V., Ridderkerk - The Netherlands

• 05/1999 Diamonde - Q Trend B.V., Ridderkerk - The Netherlands

• 09/2003 - 01/2017 Diamonde: Diamonde Shipping Ltd., Kingstown, St. Vincent and Grenadines

Remarks

Wheelhouse hydraulic lowering

Renamed

05/05 2017 Sinop

Republic of Panama, Panama City - Call sign: HP9399

Owner & manager: Sinop Shipping Corp., Istanbul - Turkey

02/2021 Sino P

Republic of Panama, Panama City - Call sign: HP9399

Owner: Dusor Lojistik ve dis Ticaret, Istanbul - Turkey

Manager: Navmarine Denizcilik Ticaret, Istanbul - Turkey

10/2021 Sino P

Togo, Lomé - Call sign: 5VIJ6

Owner: Dusor Lojistik Ve Dis Ticaret - Istanbul - Turkey

Manager: East Shipping Lines Ltd. - Amman - Jordan

Last data update

17 November 2024
