Elbrus - IMO 8916229

Name

ELBRUS

Previous names

1990 - 07.1993 Tomishima maru

1993 - 1994 Tomishima

Type

Refrigerated cargo carrier

IMO-number

8916229

Call sign

ELRD7

Flag

Liberia

Port of registry

Monrovia

GT

7.089 t

DWT

Summer: 7.242 t

NT

3.601 t

Lightweight

4.230 t

Number of 20ft containers

12 on deck

Number of 40ft containers

6 on deck

Length

146,29 m overall

Breadth

18,50 m

Draught

Summer: 7,31 m

Moulded L x B x D

138,00 x 18,50 x 10,65 m

Registered L x B x D

138,85 x 18,50 x 10,65 m

Freeboard

3.222 mm

Depth

10,65 m moulded

Speed

21,8 knots

Built

1990

Keel laid

22.12.1989

Launch date

10.04.1990

Date of completion

27.07.1990

Builder

Shikoku Dockyard Co., Ltd.
Takamatsu
Japan

Yard number

857

Hull material

Steel

Main engine

1x Mitsui B&W 6L60MC - 2 stroke single acting 6 cylinder 500 x 1.620 mm diesel engine - 6.840 kW / 9.300 hp at 133,0 rpm

Manufacturer: Mitsui Engineering & Shipbuilding Co., Ltd. Tamano Works

Propeller shaft

1x Sea water lubrication shaft

Diameter: 420 mm

Propellers

1x Pitch propeller

5 bladed - diameter: 4.725 mm

Boilers

1x Auxiliary vertical boiler - 7,9 bar

Evaporation: 2,57 t/h

Manufacturer: Tortoise Engineering Co., Ltd.

Generators

4x Yanmar M22L diesel generatorsets - 2.155 kVA

Number of holds

4

Cargo refrigerated capacity

10.579 m³ / 373.588 m³

Number of hatches

4

Hatch covers type

Main deck are hydraulic operated

Compartments

13

Cooling sections

9

Strength

Grating deck: 5,0 t/m²

Weather deck: 1,75 t/m²

Main deck: 1,70 t/m²

Tween deck: 1,70 t/m²

Tank top: 1,70 t/m²

Tank capacity

Fuel oil: 1.075 m³ / 971,2 t

Gasoil: 72,8 t

Fresh water: 241 m²

Water ballast: 1.047 m³

Cargo gear

8x Derricks/Hydraulic - SWL 4,5 t

Manager

Norbulk Shipping U.K. Ltd.

Owner

Agder Ocean Shipping
Grimstad
Norway

Registered owner

Agder Ocean Reefer II AS

Last data update

07 January 2014
