Emsrunner - IMO 9342152

Name

EMSRUNNER

Type

Multi-Purpose box single decker dry cargo ship - Equipped for carriage of containers - Strengthened for heavy cargo

IMO-number

9342152

Call sign

C4QN2

Flag

Cyprus

Port of registry

Limassol

GT

4.102 t

DWT

Summer: 5.499 t

NT

1.851 t

Number of 20ft containers

279

Number of 40ft containers

111

Container capacity 14t

243

Reefer capacity

20

Length

106,86 m overall

101,43 m registered

Breadth

15,20 m registered

Draught

5,25 m

Forecastle

8,47 m

Bridge

66,76 m

Quarterdeck

15,00 m

Freeboard

1.358 mm

Depth

6,60 m moulded

Speed

12,45 knots

Built

2006

Keel laid

30/06/1994

Launch date

13/06/2006

Date of completion

07/12/2006

Builder casco

Stocznia Sp. z.z.o.
Ustka
Poland

Builder completion

Bodewes Shipyards B.V.
Werfkade 22
9601 LG Hoogezand
The Netherlands

Yard number

670

Hull material

Shipbuilding steel (standard)

Higher tensile steel

Hull type

Double bottom, continuous from peak to peak bulkhead

Watertight bulkheads

6

Continuous decks

1

Main engine

1x MaK 6M25 - 4 stroke 6 cylinder 255 x 400 mm diesel engine - 2.010 kW at 750 rpm

Year of manufacture: 2005

Manufacturer: Caterpillar Motoren GmbH & Co. KG
Falckensteiner Str. 2
24159 Kiel
Federal Republic of Germany

Propellers

1x Controllable pitch propeller, aft at 221 rpm

Boilers

1x Water heater, oil fired - 5,0 bar

Heating surface: 8,17 m²

Year of manufacture: 2005

Manufacturer: Carbofuel Officine Meccaniche S.p.A.
Via delle Brughiere angolo Via Sicilia
20020 Bienate di Magnago
Italy

Electric installations

1x Plant 400 V - 175 kVA

1x Plant 400 V - 435 kVA

1x Plant 400 V - 175 kVA

Shaft generator

1x 435 kVA

Generators

1x Main diesel generatorset 175 kVA

Emergency - harbour gen.

1x Diesel generatorset 175 kVA

Compressed air receivers

2x Receivers each 250 litres - 30,0 bar

Bow thruster

1x Transverse thruster 300 kW, forward

Anchor equipment

3x Anchors weight each 2.280 kg

Chain length: 467,50 m

Crew size

10

Manager

Hermann Buss GmbH & Cie KG
Hafenstr. 2
26789 Leer
Federal Republic of Germany

Registered owner

Unibulk Shipping Co. Ltd.
10-12 Emmanuel Rhoides Street
3031 Limassol
Republic of Cyprus

Renamed

2018 Ketlin

Malta, Valletta - Call sign: 9HA4728

Last data update

15 August 2018
