Westerschelde 11 November 2013 |
 |
| Westerschelde 11/11/13 |
|
Name |
VAN ORCHID |
|
Type |
Bulk / Lumber carrier - Strengthened for heavy cargo |
|
IMO-number |
9553141 |
|
Call sign |
2FKC4 |
|
Flag |
Republic of Panama |
|
Port of registry |
Panama City |
|
GT |
17.018 t |
|
DWT |
Summer: 28.341 t |
|
NT |
10.109 t |
|
Length |
169,37 m |
|
Breadth |
27,00 m |
|
Draught |
Summer: 9,82 m |
|
Moulded L x Bx D |
160,40 x 27,20 x 13,60 m |
|
Registered L x B x D |
161,21 x 27,20 x 13,60 m |
|
Freeboard |
3.825 mm |
|
Depth |
13,60 m moulded |
|
Speed |
15,9 knots |
|
Built |
2009 |
|
Keel laid |
20.05.2009 |
|
Launch date |
16.10.2009 |
|
Date of completion |
27.11.2009 |
|
Builder |
Imabari Shipbuilding Marugame Yard |
|
Yard number |
1554 |
|
Hull material |
Steel |
|
Hull type |
Single hull |
|
Main engine |
1x MAN-B&W/Mitsui 6S42MC - 2 stroke single acting 6 cylinder 420 x 1.764 mm diesel engine - 5.850 kW at 129,0 rpm Manufacturer: Makita Corporation |
|
Propeller shaft |
1x Oil lubrication shaft with monitoring device Diameter: 420 mm |
|
Propellers |
1 |
|
Boilers |
1x Auxiliary Vertical boiler - 8,0 bar Evaporation: 2,07 t/h Manufacturer: Miura Co., Ltd. |
|
Generators |
4x Generators 1.715 kVA |
|
Cargo capacity |
Grain: 37.320 m³ Bales: 35.742 m³ |
|
Tank capacities |
Fuel oil: 1.369 m³ Fresh water: 308 m³ Water ballast: 8.261 m³ |
|
Manager |
Northstar Shipmanagement Ltd. |
|
Registered owner |
Rupert Investment Corporation |
|
Latest data adjustment |
09 April 2014 |
