Westerschelde 29 September 2013 |
 |
 |
 |
||
| Westerschelde 29/09/13 | Westerschelde 22/03/16 | Westerschelde 15/08/17 | ||
|
Name |
WILSON HARRIER |
|
Previous names |
1993 -2008 Laura Helena |
|
Type |
General cargo ship - Strengthened for heavy cargo |
|
IMO-number |
9064891 |
|
Call sign |
8PAP7 |
|
Flag |
Barbados |
|
Port of registry |
Bridgetown |
|
Previous flags |
1993 - 2000 Cyprus, Limassol 2000 - 2008 Malta, Valletta - Call sign: 9HJP9 |
|
GT |
2.811 t |
|
DWT |
Summer: 4.227 t Winter: 4.094 t |
|
NT |
1.688 t |
|
Number of 20ft containers |
Deck: 78 |
|
Length |
91,20 m overall 84,92 m registered |
|
Breadth |
13,80 m moulded |
|
Draught |
Summer: 5,74 m Winter: 5,62 m |
|
Keel to top antenna |
21,20 m, forward 31,80 m, aft |
|
Air draft |
26,20 m |
|
Forecastle |
6,02 m |
|
Poop |
13,80 m |
|
Depth |
7,15 m moulded |
|
Speed |
12,5 knots |
|
Built |
1993 |
|
Keel laid |
25/01/1993 |
|
Launch date |
03/06/1993 |
|
Date of completion |
01/07/1993 |
|
Builder |
Scheepswerf Pattje B.V. Waterhuizen 7 9609 PA Hoogezand The Netherlands |
|
Yard number |
384 |
|
Hull material |
Shipbuilding steel (standard) |
|
Hull type |
Double hull Partly double bottom (e.g. interrupted in way of machinery space) |
|
Watertight bulkheads |
4 |
|
Movable bulkhead |
1x Movable bulkhead in three parts, each part 2,80 m high, total height 8,40 m |
|
Continuous decks |
1 |
|
Main engine |
1x MaK 6M453C - 4 stroke 6 cylinder 320 x 420 mm combuistion engine 2.200 kW / 2.991 hp at 600 rpm Year of manufacture: 1993 Manufacturer: Krupp Mak Maschinenbau GmbH Falckensteiner Str. 2 24159 Kiel Federal Republic of Germany |
|
Propellers |
1x Controllable pitch propeller - aft at 183 rpm |
|
Electric installations |
1x Plant 380/220 V - 181 kVA 1x Plant 380 V - 270 kVA 1x Plant 380 V - 80 kVA |
|
Shaft generator |
1x 270 kVA |
|
Generators |
1x Main diesel generatorset 181 kVA |
|
Emergency generator |
1x Diesel generatorset 80 kVA |
|
Compressed air receivers |
2x Receivers each 250 litres - 30,0 bar |
|
Bow thruster |
1x Transverse thruster DANE - 210 kW, forward |
|
Number of holds |
1 Dimension: 62,63 x 11,20 x 8,43 m |
|
Total hold capacity |
Grain & bale: 5.624 m³ / 198.610 ft³ |
|
Number of hatches |
1 Dimension: 62,63 x 11,20 m |
|
Hatch type |
Pontoon |
|
Max. permissible load |
Tanktop: 12 t/m² Deck/hatch cover: 1,62 t/m² |
|
Tank capacities |
IFO: 133 m³ Water ballast: 1.594 m³ MGO: 168 m³ |
|
Anchor equipment |
3x Anchors weight each 1.920 kg Chain length: 440,00 m Diameter: 38 mm |
|
Manager |
Wilson Shipowning AS Bergen Norway |
|
Operator |
Wilson Eurocarriers AS Bergen Norway |
|
Registered owner |
Wilson Shipowning AS 5835 Bergen Norway |
|
Latest data adjustment |
15 July 2024 |
