Spijkenisse, The Netherlands 20 February 2012 |
 |
| Spijkenisse 20/02/12 |
|
Name |
TEN YU MARU |
|
Type |
Bulk carrier - Strengthened for heavy cargo |
|
IMO-number |
9520900 |
|
Call sign |
3FKB |
|
Flag |
Republic of Panama |
|
Port of registry |
Panama City |
|
GT |
32.305 t |
|
DWT |
Summer: 58.110 t |
|
NT |
19.458 t |
|
Length |
189,99 m overall |
|
Breadth |
32,26 m |
|
Draught |
Summer: 12,83 m |
|
Moulded L x B x D |
185,60 x 32,26 x 18,00 m |
|
Registered L x B x D |
185,78 x 32,26 x 18,00 m |
|
Freeboard |
5.225 mm |
|
Depth |
18,00 m moulded |
|
Speed |
15,4 knots |
|
Built |
2010 |
|
Keel laid |
19.07.2010 |
|
Launch date |
11.09.2010 |
|
Date of completion |
05.11.2010 |
|
Builder |
Tsuneishi Group (Zhoushan) Shipbuilding Inc. Fukuyama |
|
Yard number |
SS-069 |
|
Hull material |
Steel |
|
Main engine |
1x MAN-B&W/Mitsui 6S50MC - 2 stroke single acting 6 cylinder 500 x 2.000 mm diesel engine - 8.400 kW / 10.600 hp at 113,0 rpm Manufacturer: Mitsui Engineering & Shipbuilding Co., Ltd. |
|
Propeller shaft |
1x Oil lubrication shaft without monitoring device |
|
Propellers |
1 |
|
Boilers |
1x Auxiliary vertical boiler - 7,0 bar Evaporation: 2,58 t/h Manufacturer: Osaka Boiler Mfg., Co., Ltd. |
|
Generators |
4x Generators - 1.900 kVA |
|
Cargo capacity |
Bales: 70.122 m³ Grain: 72.689 m³ |
|
Tank capacities |
Fuel oil: 2.388 m³ Fresh water: 313 m³ Water ballast: 16.437 m³ |
|
Manager |
UMMS - Union Marine Management Services Pte Ltd. Republic of Singapore |
|
Registered owner |
Chijin Shipping S.A. |
|
Latest data adjustment |
28 June 2014 |
