Westerschelde 17 February 2019 |
 |
 |
 |
 |
 |
 |
|||||
| Antwerpen 04/05/14 | Antwerpen 04/05/14 | Antwerpen 14/05/14 | Antwerpen 26/08/17 | Antwerpen 26/08/17 | Antwerpen 26/08/17 |
|
Name |
RENATE |
|
Type |
Bulk carrier - Single decker - Strengthened for heavy cargo |
|
IMO-number |
9628817 |
|
Previous classification |
DNV GL SE |
|
Call sign |
A8ZN6 |
|
Flag |
Liberia |
|
Port of registry |
Monrovia |
|
GT |
24.245 t registered |
|
DWT |
Summer: 34.500 t |
|
NT |
11.510 t registered |
|
Length |
179,93 m overall |
|
Breadth |
30,00 m moulded |
|
Draught |
Summer: 10,12 m |
|
Moulded L x B x D |
176,75 x 30,00 x 14,70 m |
|
Registered Lx B x D |
176,75 x 30,00 x 14,70 m |
|
Freeboard |
Summer: 4.630 mm |
|
Depth |
14,70 m moulded |
|
Speed |
14,0 knots |
|
Built |
2013 |
|
Keel laid |
15/12/2011 |
|
Launch date |
14/11/2012 |
|
Date of completion |
17/06/2013 |
|
Builder |
Zhong Chuan Heavy Industry Shipbuilding Co., Ltd. Xingang Industrial Park Zhoushan, Zhejiang People's Republic of China |
|
Yard number |
ZC3008 |
|
Hull material |
Shipbuilding steel (standard) Higher tensile steel |
|
Hull type |
Double bottom, continuous from peak to peak bulkhead |
|
Watertight bulkheads |
7 |
|
Continuous decks |
1 |
|
Main engine |
1x 5S50MC-C8 TII - 2 stroke 5 cylinder 500 x 2.000 mm diesel engine - 8.300 kW at 110,0 rpm Year of manufacture: 2011 Manufacturer: Jiangsu Antai Power Machinery Co.,Ltd 9 Liuzhugang Road Xingang Park Zone Jingjiang City, Jiangsu People's Republic of China |
|
Propeller shaft |
1x Oil lubrication shaft without monitoring device Diameter: 450 mm |
|
Propellers |
1x Solid propeller (keyless) - aft at 110,0 rpm |
|
Boilers |
1x Steam boiler, oil fired - 9,0 bar Heating surface: 16,9 m² 1x Steam boiler, exhaust gas heated - 9,0 bar Heating surface: 133,8 m² Year of manufacture: 2012 Manufacturer: Saacke Qingdao Marine Boiler Co., Ltd. Machinery Industry Park Qingdao Development Area Qingdao, 266500 Shandong People's Republic of China |
|
Electric installations |
3x Plants each 450 V - 750 kVA 1x Plant 450 V - 137,5 kVA 1x Plant 12 V - 100 Ah 1x Plant 12 V - 195 Ah 1x Plant 12 V - 200 Ah 1x Plant 12 V - 200 Ah |
|
Generators |
3x Main diesel generatorsets each 750 kVA |
|
Emergency generator |
1x diesel generatorset 137,5 kVA |
|
Batteries |
1x Battery for UPS navigation 200 Ah 1x Battery for automation 200 Ah 1x Battery for start emergency engine 195 Ah 1x Battery for UPS radio 100 Ah |
|
Compressed air receivers |
2x Receivers each 5.000 litres - 30,0 bar 1x Receiver 200 litres - 30,0 bar 1x Receiver 2.000 litres - 8,0 bar 1x Receiver 500 litres - 8,0 bar 1x Receiver 100 litres - 8,0 bar |
|
Number of holds |
5 |
|
Hold capacity |
Bale: 45.670 m³ Grain: 46.748 m³ |
|
Number of hatches |
5 |
|
Tank capacities |
Fuel oil: 1.948 m³ Fresh water: 250 m³ |
|
Anchor equipment |
3x Anchors weight each 7.800 kg Chain length: 632,50 m |
|
Cargo gear |
4x Cranes - SWL 30,0 t each |
|
Crew size |
25 |
|
Manager |
MST - Mineralien Schiffahrt Spedition und Transport GmbH Am Ruttmann Kai 1 (Alte Kolonie) 92253 Schnaittenbach Federal Republic of Germany |
|
Registered owner |
(Bareboat Charterer) Renate Shipping Ltd. |
|
Latest data adjustment |
03 March 2018 |
