Antwerpen 27 August 2014 |
 |
 |
 |
||
| Antwerpen 27/08/14 | Antwerpen 17/07/19 | Westerschelde 21/08/20 |
|
Name |
FAST JEF |
|
Previous names |
1996 - 11/1997 Breehorn |
|
Type |
General cargo ship - Heavycargo |
|
IMO-number |
9136101 |
|
Call sign |
ONEE |
|
Flag |
Belgium |
|
Port of registry |
Antwerpen |
|
Previous flags |
1996 - 11/1997 The Netherlands, Rotterdam - Call sign: PCXH 11/1997 - 06/2006 The Netherlands, Harlingen - Call sign: PCXH |
|
GT |
2.066 t |
|
DWT |
Summer: 3.202t |
|
DWCC |
Summer: 3.100 t Winter: 3.000 t |
|
NT |
1.143 t |
|
Number of 20ft containers |
154 |
|
Length |
87,90 m overall 83,80 m between perpendiculars |
|
Breadth |
12,53 m overall |
|
Draught |
Summer: 4,65 m |
|
Keel to mast end |
19,80 m |
|
Air draft |
12,50 m |
|
Freeboard |
1.180 mm |
|
Depth |
6,00 m |
|
Speed |
11,0 knots |
|
Built |
1996 |
|
Keel laid |
01/1996 |
|
Launch date |
16/08/1996 |
|
Date of completion |
12/09/1996 |
|
Builder |
Scheepswerf & Machinefabriek Barkmeijer Stroobos B.V. Stroobos The Netherlands |
|
Yard number |
283 |
|
Hull material |
Steel |
|
Continuous decks |
1 |
|
Movable bulkhead |
2 |
|
Main engine |
1x MaK 8M20 - 4 stroke single acting 8 cylinder 200 x 300 mm combustion engine 1.000 kW /1.358 hp at 900 rpm Starter type: Compressed air Built: 1996 Builder: Krupp MaK Maschinenbau GmbH, Kiel - Germany |
|
Gearbox |
1x Lohmann & Stolterfoht Navilus GWE-39 - Reduction: 3,952:1 |
|
Propellers |
1x Screw Propeller Solid - aft at 400 rpm Diameter: 2.350 mm - 5 Blades |
|
Electric installations |
Power voltage: 380 V Lighting voltage: 220 V Frequency: 50 Hz |
|
Generators |
2x Valmet 620DSG - 6 cylinder 108 x 120 mm engines each 90 kW connected with Stamford UCM-274E23 generators each 112 kVA at 1.500 rpm Built: 1996 |
|
Emergency generator |
1x Valmet 320DSG - 3 cylinder 108 x 120 mm engine 53 kW connected with a Stamford UCM-224G23 generator 60 kVA at 1.500 rpm Built: 1996 |
|
Bow thruster |
1x Scania DS-11 / Veth VT-150 - 220 kW |
|
Number of holds |
1 61,80 x 10,20 x 6,64 m |
|
Total capacity of holds |
Grain & Bales: 3.235 m³ / 145.350 ft³ |
|
Number of hatches |
1 61,80 x 10,20 m |
|
Hatch type |
Pontoon |
|
Deck strength |
Tanktop: 12 t/m² |
|
Fuel capacity |
175 m³ |
|
Lifting equipment |
1x Gantry crane - SWL 15,0 t 1x Boot crane - SWL 1,0 t at 3,00 m |
|
ISM & Commercial manager |
Fast Baltic Sp. z.o.o. ul Bytomska 7 70-603 Szczecin (Stettin) Poland |
|
Previous managers |
1996 - 11/1997 Rederij 'Zodiac', Rotterdam - The Netherlands 11/1997 - 06/2016 Poseidon Chartering B.V., Delfzijl - The Netherlands |
|
Registered owner |
Fast Lines Belgium N.V. Ernest Van Dijckkaai 15/17 Antwerpen Belgium |
|
Previous names &owners |
09/1996 Breehorn - Rederij Zodiac, Harlingen - The Netherlands 11/1997 Fast Jef - Rederij Zodiac, Harlingen - The Netherlands 06/2006 Fast Jef - Fast Lines Belgium NV Belgium, Antwerpen, Belgium |
|
Latest data adjustment |
16 January 2022 |
