Westerschelde 15 October 2013 |
 |
| Westerschelde 15/10/13 |
|
Name |
PILION |
|
Type |
Bulk carrier |
|
IMO-number |
9425825 |
|
Call sign |
8PWL |
|
Flag |
Barbados |
|
Port of registry |
Bridgetown |
|
GT |
32.210 t |
|
DWT |
Summer: 58.081 t |
|
NT |
19.405 t |
|
Length |
189,99 m overall 185,60 m between perpendiculars |
|
Breadth |
32,26 m |
|
Draught |
12,83 m |
|
Freeboard |
5.225 mm |
|
Depth |
18,00 m |
|
Speed |
Service: 14,5 knots Max.: 15,5 knots |
|
Built |
2010 |
|
Keel laid |
14.05.2010 |
|
Launch date |
03.07.2010 |
|
Date of completion |
28.08.2010 |
|
Builder |
Tsuneishi Heavy Industries (Cebu), Inc. |
|
Yard number |
SC 116 |
|
Hull material |
Mild steel |
|
Watertight compartment |
7 |
|
Continuous decks |
1 |
|
Main engine |
1x MAN-B&W/Mitsui 6S50MC-C - 2 stroke single acting 6 cylinder 500 x 2.000 mm diesel engine - 8.400 kW / 11.413 hp at 113,0 rpm Builder: Mitsui Engineering & Shipbuilding Co., Ltd., Okayama - Japan |
|
Propellers |
1x Screw propeller solid - aft at 113 rpm |
|
Boilers |
1x CHM 3433KOB10 - 151,00 m² - 6,0 bar |
|
Generators |
3x Main diesel generatorsets each 600 kVA - 480 kW - 720 hp |
|
Emergency generator |
1x Diesel generatorset 100 kVA - 80 kW - 143 hp |
|
Number of holds |
5 |
|
Total capacity of holds |
70.064,40 m³ |
|
Fuel capacity |
2.389,3 m³ |
|
Manager |
Helikon Shipping Enterprise |
|
Registered owner |
Pilion Navigation S.A. |
|
Latest data adjustment |
26 October 2014 |
