Cadiz - Spain 20 September 2014 |
|
Name |
CASTLE ISLAND |
|
Previous names |
1997 - 08.2004 Atlantic Trader |
|
Type |
Bulk / Lumber carrier - Handysize |
|
IMO-number |
9159749 |
|
Call sign |
VRYL2 |
|
Flag |
Hong Kong - China |
|
Port of registry |
Hong Kong |
|
GT |
17.377 t registered |
|
DWT |
Summer: 28.759 t |
|
NT |
10.133 t registered |
|
Length |
176,62 m overall |
|
Breadth |
26,00 m |
|
Draught |
Summer: 9,63 m |
|
Moulded L x B x D |
169,40 x 26,00 x 13,60 m |
|
Registered L x B x D |
170,140x 26,00 x 13,60 m |
|
Freeboard |
4.018 mm |
|
Depth |
13,60 m moulded |
|
Speed |
16,3 knots |
|
Built |
1997 |
|
Keel laid |
28.01.1997 |
|
Launch date |
27.03.1997 |
|
Date of completion |
25.06.1997 |
|
Builder |
Shin Kurushima Dockyard Co., Ltd. |
|
Yard number |
2923 |
|
Hull material |
Steel |
|
Hull type |
Single hull |
|
Main engine |
1x 2 stroke single acting 5 cylinder 520 x 1.600 mm diesel engine - 8.884 kW at 133,0 rpm Manufacturer: Kobe Diesel Co., Ltd. Nagasaki Works |
|
Propeller shaft |
1x Oil lubrication shaft without monitoring device Diameter: 630 mm |
|
Propellers |
1 |
|
Boilers |
1x Auxiliary vertical boiler - 6,9 bar Evaporation: 1,77 t/h Manufacturer: Tortoise Engineering Co., Ltd. |
|
Generators |
3x Generators 1.090 kVA |
|
Hold capacity |
Grain: 39.037 m³ Bales: 38.043 m³ |
|
Tank capacities |
Fuel oil: 1.230 m³ Fresh water: 239 m³ Water ballast: 9.371 m³ |
|
Cargo gear |
4x Cranes - SWL 30,0 t each |
|
Manager |
Pacific Basin Shipping (HK) Limited |
|
Registered owner |
TRS Delft Zuid B.V. The Netherlands |
|
Latest data adjustment |
02 November 2014 |
