Spijkenisse, The Netherlands 21 April 2012 |
 |
| Spijkenisse 15/05/12 |
|
Name |
VLAS NICHKOV |
|
Russian name |
ВΛΑС НИЧΚΟΒ |
|
Type |
General cargo ship - Timber carrier |
|
Main products |
Wood packaged - Wood logs - Grain - Container facility |
|
IMO-number |
7362419 |
|
Call sign |
UCMV |
|
Flag |
Russian Federation |
|
Port of registry |
Arkhangelsk |
|
GT |
10.133 t |
|
DWT |
Summer: 14.204 t |
|
NT |
4.994 t |
|
Displacement |
19.730 t full load |
|
Number of 20ft containers |
308 |
|
Length |
151,75 m 139,87 m |
|
Breadth |
21,06 m |
|
Draught |
Summer: 8,69 m |
|
Keel to top antenna |
41,50 m |
|
Depth |
11,60 m to keel |
|
Keel to top of hatch covers |
13,20 m |
|
Speed |
Service: 15,80 knots |
|
Built |
1974 |
|
Date of completion |
30.12.1973 |
|
Builder |
Stocznia Gdanska im Lenina |
|
Yard number |
B540/01 |
|
Hull material |
Steen |
|
Watertight bulkheads |
8 |
|
Continuous decks |
1 |
|
Main engine |
1x Sulzer 6RND68 diesel engine - 9.900 bhp / 7.382 kW at 150 rpm Built: 1973 |
|
Propellers |
1x Fixed pitched solid propeller |
|
Generators |
3x Diesel generatorsets each 504 kVA |
|
Number of holds |
5 Hold 1: 8,40 + 9,0 x 5,360 / 13,00 x 9,08 m Hold 2: 20,00 x 17,20 x 10,48 m Hold 3: 19,80 x 17,20 x 10,48 m Hold 4: 19,60 x 17,20 x 10,48 m Hold 5: 19,60 x 17,20 x 10,48 m |
|
Cargo capacity |
Bale: Hold 1: 1.721 m³ Hold 2: 3.777 m³ Hold 3: 3.783 m³ Hold 4: 3.777 m³ Hold 5: 3.722 m³ Total: 16.780 m³ Grain: Hold 1: 1.760 m³ Hold 2: 3.875 m³ Hold 3: 3.875 m³ Hold 4: 3.875 m³ Hold 5: 3.821 m³ Total: 17.206 m³ |
|
Number of hatches |
5 Hatch 1: 6,00 + 6,70 x 9,10 + 11,60 m Hatch 2: 15,30 x 7,70 + 7,70 m Hatch 3: 15,30 x 7,70 + 7,70 m Hatch 4: 15,30 x 7,70 + 7,70 m Hatch 5: 15,10 x 7,70 + 7,70 m |
|
Deck space for cargo |
1.050 m² |
|
Max. permissible loading |
Hatch cover: 1,75 t/m² On deck: 2,30 t/m² Tank top: N° 1: 8,01 t/m² N° 2-5: 10,39 t/m² |
|
Tank capacities |
Fresh water: 170 t Bunker: 1.767 m³ Water ballast: 4.146 t |
|
Lifting equipment |
9x Derricks - SWL 10,0 t each |
|
Crew |
19 |
|
Owner |
Arkhangelsk NSC |
|
Registered owner |
"Northern Shipping Company", Joint-Stock Company |
|
Sister ships |
Fedor Varaksin Petr Strelkov |
|
Scrapped |
08.2012 at Aliaga - Turkey |
|
Latest data adjustment |
15 November 2014 |
