Westerschelde 23 February 2012 |
 |
 |
|
| Westerschelde 23/02/12 | Westerschelde 23/02/12 |
|
Name |
SIDERFLY |
|
Previous names |
1985 - 1999 Borgfeld 03.1999 -05.1999 Eemsea 05.1999 - 10.2001 Borgfeld |
|
Type |
Multipurpose vessel for transport of bulk, steel coils, forest products, general cargoes |
|
IMO-number |
8412405 |
|
Call sign |
J8B2805 |
|
Flag |
Saint Vincent & Grenadines |
|
Port of registry |
Kingstown |
|
GT |
2.882 t |
|
DWT |
Summer: 4.380 t |
|
NT |
1.588 t |
|
Displacement |
5.836 t |
|
Number of 20ft containers |
158 |
|
Length |
99,80 m overall 94,52 m between perpendiculars |
|
Breadth |
14,60 m overall |
|
Draught |
5,42 m |
|
Depth |
6,96 m moulded |
|
Speed |
Service: 10,0 knots |
|
Built |
1985 |
|
Keel laid |
27.08.1984 |
|
Launch date |
23.03.1985 |
|
Date of completion |
24.06.1985 |
|
Builder |
Elsflether Werft |
|
Yard number |
408 |
|
Hull material |
Steel |
|
Bulkheads |
5 |
|
Number of decks |
1 |
|
Main engine |
1x Deutz SBV 8M 628 - 8 cylinder diesel engine 1.228 kW / 1.670 hp Built: 1984 Germany |
|
Propellers |
1x Fixed pitched solid propeller - 4 blades |
|
Generators |
2x Diesel generatorsets each 178 kVA |
|
Emergency generator |
1x Diesel generatorset 49 kVA |
|
Bow thruster |
1x 150 kW |
|
Number of holds |
2x Box shape Hold 1: 28,73 x 11,60 x 7,18-7,20 m Hold 2: 38,60 x 11,60 x 7,18 |
|
Hold capacity |
Grain/bales: Hold 1: 2.246 m³ Hold 2: 3.106 m³ Total: 5.352 m³ / 189.000 ft³ |
|
Number of hatches |
2 Hatch 1: 23,22 x 12,04 m Hatch 2: 37,48 x 11,60 m |
|
Hatch type |
Steel hatch covers, Mc Gregor type |
|
Max. permissible load |
On deck: 2,5 t/m² Tanktop: 7,0 t/m² |
|
Tank capacities |
Fuel oil: 156 t Water ballast: 1.647 t |
|
Crew |
9 |
|
Registered owner |
Dleclass Shipping Co. Ltd. |
|
Scrapping |
02.2014 By Fornaes Shipbreaking Ltd., Grenaa - Denmark |
|
Latest data adjustment |
22 December 2014 |
