Malaga - Span 23 February 2015 |
|
Name |
VEGADIEP |
|
Previous names |
2005 - 03/2010 UAL Coburg 03/2010 - 05/2011 OSC Vegadiep 05/2011 - 06/2012 UAL Ghana |
|
Type |
Multi-purpose vessel, Geared & Tweendecker Strengthened for heavy cargoes - Container cargoes in hold and on hatchcovers |
|
IMO-number |
9317808 |
|
Call sign |
PBHV |
|
Flag |
The Netherlands |
|
Port of registry |
Groningen |
|
GT |
5.057 t |
|
DWT |
Summer: 7.709 t |
|
NT |
2.663 t |
|
Lightweight |
2.669 t |
|
Number of 20ft containers |
On hatch: 199 In hold: 174 Total: 373 |
|
Number of 40ft containers |
On hatch: 88 + 23 TEU In hold: 84 + 6 TEU Total: 172 + 29 TEU |
|
Container capacity 14t |
238 |
|
Reefer plugs |
Hold 2: 10 |
|
Length |
119,98 m overall 113,35 m between perpendiculars |
|
Breadth |
Max.: 15,20 m |
|
Draught |
Max.: 7,03 m |
|
Depth |
8,45 m to main deck |
|
Speed |
14,0 knots |
|
Built |
2005 |
|
Date of completion |
04/02/2005 |
|
Builder casco |
ATVT Sudnobudivinyi Zavod Zaliv |
|
Builder completion |
Bodewes Shipyard The Netherlands |
|
Yard number |
643 |
|
Hull material |
Steel |
|
Continuous decks |
1 |
|
Main engine |
1x Mak 8M32 - 4 stroke single acting 8 cylinder 320 x 480 mm combustion engine 3.840 kW / 5.222 bhp Manufacture : M.A.K. Caterpillar, Kiel, - Germany |
|
Propellers |
1 |
|
Generators |
3x Scania main diesel generatorsets each 310 kW |
|
Emergency generator |
2x Diesel generatorset 110 kW |
|
Bow thruster |
1x 400 kW |
|
Number of holds |
2 |
|
Hold capacity |
Hold 1: 4.306 m³ /152.062 ft³ Hold 2: 5.288 m³ /186.740 ft³ Total: 9.594 m³ /338.802 ft³ |
|
Number of hatches |
2 Hatch 1: 39,00 x 12,65/5,50 m Hatch 2: 44,25 x 12,65 m |
|
Hatch cover |
Pontoon type |
|
Deck strength |
Tanktop: 15,0 t/m² Tweendeck: 3,5 t/m² Hatchcover: 1,75 t/m² |
|
Ventilation |
10x air-changes per hour |
|
Tank capacities |
HFO 98%: 545 m³ MGO 98%: 80 m³ Fresh water: 50 m³ Water ballast: 3.319 m³ |
|
Cargo gear |
2x NMF cranes - SWL 60,0 t each Max. outreach: 25,00 m |
|
Crew size |
12 |
|
Manager |
Feederlines The Netherlands |
|
Operator |
MTL |
|
Owner |
Beheermaatschappij Vegadiep B.V. The Netherlands |
|
Previous names & owners |
02/2005 UAL COBURG - C.V. Scheepvaartonderneming Vegadiep, Groningen - The Netherlands 03/2010 OSC Vegadiep - C.V. Scheepvaartonderneming Vegadiep, Groningen - The Netherlands 05/2011 UAL Ghane - Beheermaatschappij Vegadiep B.V., Groningen - The Netherlands 06/2012 Vegadiep - Beheermaatschappij Vegadiep B.V., Groningen - The Netherlands |
|
Renamed |
06/2015 Tip Bremen Malta, Valletta - Cal sign: 9HA3941 Manager: TIP Bremen GmbH & Company K.G., Bremen - Germany Owner:Liberty One Shipmanagement GmbH & Co. K.G., Bremen - Germany |
|
Latest data adjustment |
30 May 2019 |
